Start up
© Festo Didactic GmbH & -transfer system 63
3.3.5 37 pol Sub-D socket (X2) at module distributor
Socket X2 - Occupation
PIN
Bit
Description
PIN
Bit
Description
01
0V
Powers supply
20
0V
Power supply
02
0
PLC IN / Em.4 / X4:1
21
6
PLC IN / Em.3 / X3:7
03
2
PLC IN / Em.5 / X4:2
22
4
PLC IN / Em.2 / X3:5
04
4
PLC IN / Em.6 / X4:3
23
2
PLC IN / Em.1 / X3:3
05
6
PLC IN / Em.7 / X4:4
24
0
PLC IN / Em.0 / X3:1
06
0
PLC IN / En.4 / X6:1
25
6
PLC IN / En.3 / X5:7
07
2
PLC IN / En.5 / X6:3
26
4
PLC IN / En.2 / X5:5
08
4
PLC IN / En.6 / X6:5
27
2
PLC IN / En.1 / X5:3
09
6
PLC IN / En.7 / X6:7
28
0
PLC IN / En.0 / X5:1
10
29
0
PLC IN / Eo.4 / X8:1
11
6
PLC IN / Eo.3 / X7:7
30
2
PLC IN / Eo.5 / X8:3
12
4
PLC IN / Eo.2 / X7:5
31
4
PLC IN / Eo.6 / X8:5
13
2
PLC IN / Eo.1 / X7:3
32
6
PLC IN / Eo.7 / X8:7
14
0
PLC IN / Eo.0 / X7:1
33
15
34
16
35
17
36
18
37
24V
Power supply
19
24V
Power supply
