Festo SFC-DC Series User Manual

Festo P.BE−K−SFC−DC−... 0801c English19
Connection on the SFC−DC−... Description
3
Controller
interface
 Sub−D 15−pin
 Plugs
SFC−DC−...−IO:
I/O interface for connecting to
any PLC controller
 Sub−D 9−pin
 Socket
SFC−DC−...−PB:
PROFIBUS−DP interface
 Sub−D 9−pin
 Plugs
SFC−DC−...−CO:
CANopen interface
 Sub−D 9−pin
 Plugs
SFC−DC−...−DN:
DeviceNet interface
4
Earth
terminal
M4 stud bolt Connection for functional earth
(optionally via power supply
cable)
5
Power sup
ply
 DSub−7W2
 Plugs
Operating voltage connection
with high−current contacts
6
SLTE,
HGPLE,
HGPPE
(motor)
 Sub−D 15−pin
 Socket
Controlling the motor with en
coder signals
7
Serial inter
face
 M8, 4−pin
 Socket
RS−232 interface for
parameterizing, commissioning
and diagnosing
8
Reference
switch
 M8, 3−pin
 Socket
Sensor input for reference
switch
