10
* Speed specifications with fully charged battery pack.
Functional description
The pictures for the functional description are on a
fold-out page at the beginning of the instruction
manual. When reading of the manual you can fold
out this page for having always an overview of the
machine.
Intended use
The drywall screwdriver is designed for the follow-
ing works:
DWC 18-4500
– Gypsum plaster boards on metal profile rails (≤
0.88 mm) with drywall screws with fine thread
– Gypsum plaster boards on metal profile rails (≤
2.25 mm) with drywall screws, self-drilling
– Gypsum plaster boards on wooden constructions
with drywall screws with coarse thread
DWC 18-2500
– Gypsum fibre boards on metal and wooden con-
structions with drywall screws with milling ribs
– Chip boards/OSB on wooden constructions with
wood construction and chip board screws up to
dia. 5 mm
Weight with magazine attachment (without
battery pack)
1.5 kg 1.5 kg
Cordless drywall screwdriver DWC 18-2500 DWC 18-4500
Charger TCL 3
Mains voltage (input) 120 V ~
Mains frequency 60 Hz
Charging voltage (output) 10,8 - 18 V=
Rapid charging max. 3 A
Conservation charging, intermittent (NiCd, NiMH) approx. 0,06 A
Charging times for BP, BPS and BPC battery packs
Li-ion 1,5 Ah, 80 %/100 % approx. 25/35 min.
Li-ion 3,0 Ah, 80 %/100 % approx. 55/70 min.
Li-ion 4,2 Ah, 80 %/100 % approx. 70/90 min.
Permitted operating temperature range -5 °C to +45°C
Temperature monitoring via NTC resistor
Safety class /II
Battery pack BPC 18
Voltage 18 V
Capacity 4.2 Ah
Weight 0.7 kg
[1-1]
Bit store
[1-2]
On/Off switch
[1-3]
Right/left switch
[1-4]
AUTO/MAN switch
[1-5]
Depth stop
[1-6]
Bit
