Depth stop disassembly
Remove the depth stop from the gear box by
pulling it.
Scaffolding holder and belt clip
Use the belt clip
[8-1]
to temporarily attach the
screwdriver on the working clothing – it can be at-
tached by means of a screw
[8-2]
to the left or right
of the power tool, and it is suitable for right and left
handed people – see figure
[8]
.
The screwdriver is equipped with a scaffolding
holder
[9-1]
which is used for occasional machine
suspension. It can be attached to the left or right of
the power tool, by means of a screw
[9-2]
– see fig-
ure
[9]
.
Magazine attachment
The magazine attachment enables to work contin-
uously, without unnecessary delays.
Fitting the magazine attachment
At first remove the depth stop
[7-1]
, bit holder
[5-2]
and bit, as specified in chapter Tool holder,
attachments.
Set the switch
[1-4]
into MAN position.
Push the long bit
[10-1]
completely to the hex-
agonal spindle opening
[10-2]
.
Then fit the magazine attachment on the gear
box. Push the attachment until it engages in the
groove of the gear box.
The magazine attachment can be mounted at
30° steps.
Removing the magazine attachment
Use power to carefully pull the magazine at-
tachment from the gear box.
Setting the screw length
Press button
[11-1]
to remove and insert the
depth stop
[11-2]
and set the required screw
length.
Read the set screw length on the depth stop sides
[11-3]
.
