Fetco CBS-2152XTS - CBS-2151,XTS Tank Parts List; Tank Component Parts

25
CBS-2151,XTS Drawing 1109.00076.00 SERVICE PARTS, TANK
ITEM NO PART NO DESCRIPTION QTY
1
1023.00166.00 FITTING, COLD WATER INLET, GROMMET DESIGN 1
2
1024.00053.00 LEVEL AND TEMP PROBE GROMMET 2
3
1102.00161.00 PROBE ASSEMBLY, TEMP. AND LLC, HWD-2100 1
4
1112.00019.00 PROBE WELDMENT, WATER LEVEL 2.600" LG 1
5
1107.00005.00 HEATER ASSEMBLY, IMMERSION 3000W/240VAC 2
6
1024.00007.00 O-RING, DASH #344, TANK COVER 1
7
1102.00007.00 TANK COVER ASSEMBLY 1
8
1003.00005.00 BRACKET, ONE SHOT THERMOSTAT 2
9
1053.00003.00 THERMOSTAT, SINGLE SHOT, 240V/40A 2
10
1003.00140.00 ALUMINUM BRACKET FOR SSR 2
11
1052.00033.00 RELAY, SOLID STATE, 50A/480VAC, W/BUILD IN VARISTOR 2
12
1081.00042.00 STANDOFF, 1/4" HEX 4
13
1022.00068.00 INSULATION, TANK FRONT, CBS-2151 1
14
1022.00069.00 INSULATION, TANK BACK, CBS-2151 1
