Fetco CBS-2152XTS - Back Panel Service Parts (Continued); CBS-2151,XTS UL Back Panel Parts; CBS-2151,XTS CE Back Panel Parts

27
CBS-2151,XTS Drawing 1109.00092.00 SERVICE PARTS, BACK PANEL-UL
ITEM NO PART NO DESCRIPTION QTY
1 1052.00002.00 TERMINAL BLOCK, 3 POLE, W/ MARKING STRIP 1
2 1086.00008.00 CONNECTOR, CABLE CLAMP, 3/4" 1
3 1058.00020.00 SWITCH, PWR ROCKER RED, ILLUM. 250VAC 1
4 1052.00001.00 POWER SUPPLY, 90-264VAC/24VDC, 1.8A 1
5 1029.00012.00 SPACER, .25" HEX X 1" LG, FEM #4-40 THREAD 4
CBS-2151,XTS Drawing 1109.00048.00 SERVICE PARTS, BACK PANEL-CE
ITEM NO PART NO DESCRIPTION QTY
1
1052.00001.0
POWER SUPPLY, 90-264VAC/24VDC, 1.8A 1
2
1058.00024.0
SWITCH, POWER, DOUBLE POLE, 16A, 125/250 VAC 1
3
1086.00031.0
BUSHING, STRAIN RELIEF, BLACK, .354"-.630" 1
4
1052.00022.0 EUROSTRIP HE6 TERM. BLK., 3 POLE, 40AMP,10-20 TERM.
1
5
1029.00012.0
LOCKNUT, HEX BLACK, FOR SKINTOP RELIEF 1
