Fetco CBS-2152XTS - General Brewer Settings Configuration; Tank and Brew Temperature Settings; Units, ECO Mode, and Sensor Settings; Altitude Adjustment for Boiling Point

8
INPUTS
Programming
Items
Factory set
Default
Programming Range
(display)
Notes
Display Inputs
• Input Summery
R. Brew Basket Sens. [ single/dual]
L. Brew Basket Sens.
H. Liquid Level probe
H. Tank Temperature Probe
L. Tank Temperature Probe
SD Card Recognized
Tank Temp. 200






Cal. Touch Scr
Calibrate
Calibrate
________________[]____
YES NO
If Yes:
Follow directions on the
touch screen
GENERAL
Programming
Items
Factory set
Default
Programming Range
(display)
Notes
Tank Temp.
200°F
200 °F
|______________[]__
_|
170 207
Correction for high
altitude below
Brew at Temp.
“OFF” allows
brewing at any
temperature.
“ON”
ON
|________[]_______|
OFF ON AUTO
SEE NOTE BELOW!
Units of Meas.
• Temperature
°C or °F
°F
|___[]____________|
°F °C
[Switchable Units]
• Volume
Gallons [Liters]
Gallons
|___[]____________|
Gallons Liters
[Switchable Units]
ECO Mode
Energy Saving
Mode
OFF
ECO Mode
_______________[]
_____
ON OFF
If Selected: Lowers hot
water tank temperature to
170°F after 1 hour of
inactivity
Logo Timeout
0:30 mm:ss
0:30 mm:ss
|__[]
___________|
0:15 5:00
Brew B. Sensor
NORMAL
NORMAL
|__[]
____________|
NORMAL OVERRIDE
Factory or service use for
servicing. “NORMAL” is
recommended for safety.
Use Flowjet
NO
NO
____[]
_______________
NO YES
Trims water handling
system for Flowjet
LLC Sensitivity
Normal for most water
“HIGH” for R.O.
NORMAL
NORMAL
____[]________
______
NORMAL HIGH
Sets sensitivity for liquid level
control.
High is for reverse osmosis
water or very pure water.
Chart to correct fo
r
altitude for boiling point
in tank water temperature.
[ft] [m]
Suggested
Setting[°F]
Boiling
point[°F]
Suggested
Setting[°C]
Boiling
point [°C]
0 0 200 212.0 93 100.0
500 152 200 211.0 93 99.5
1000 305 200 210.1 93 98.9
2000 610 200 208.1 93 97.8
2500 762 200 207.2 93 97.3
3000 914 200 206.2 93 96.8
3500 1067 197 205.3 92 96.3
4000 1219 195 204.3 91 95.7
4500 1372 194 203.4 90 95.2
5000 1524 194 202.4 90 94.7
5500 1676 193 201.5 89 94.2
6000 1829 192 200.6 89 93.6
6500 1981 191 199.6 88 93.1
7000 2134 190 198.7 87 92.6
7500 2286 188 197.8 86 92.1
8000 2438 187 196.9 86 91.6
8500 2591 185 196.0 85 91.1
BREW AT TEMPERATURE DEFINITONS
BREW AT TEMP: “ON”
(DEFAULT: FACTORY PROGRAMMED INTO BREWER)
“BREW START” Batch Section Buttons will not be accessible until
tank temperature is at set point.
The “BREW START” screens with the Batch Section Buttons
become accessible when hot water tank is at the selected
temperature. The screen at right displays when the “BREW AT
TEMP” is selected.
BREW AT TEMP: AUTO USER SELECTABLE
This allows the “BREW START” to activate if the hot water tank is
at the selected temperature—then brew will start.
If the temperature is too low, the brewer will wait until the proper
temperature is reached. A screen (example to the right) will
display showing a thermometer icon and the tank temperature.
IMPORTANT: ALWAYS have dispenser(s) under the brew
baskets when in the BREW AT TEMP mode.
BREW AT TEMP: OFF USER SELECTABLE (Not recommended)
Allows brewing at any temperature above 179°F/82°C.
May NOT apply for two sided brewer if one side is in brew cycle
CBS_2132 3L
 Ready Tank Temp °F
 Heating
197
 Filling
XTS
XTS™
EXTRACTOR
TOUCHSCREEN
Regular 1
1.50
 05:30
Regular 2
1.50
 05:30
Deca
f
1
1.50
 05:30
Decaf 2
1.00
 05:30
92°
C
INFO
STOP
