Go to fetco.com for the latest versions of all information Page 13 CBS-7000 Series Brewers & Dispensers P186 JANUARY 2020
ITEM # QTY PART # DESCRIPTION Drawing No. 1101.00543.00 CBS-72A Brew head only
1
1
001076
WELDMENT, CBS-72A
2
4
1086.00011.00
BUSHING, SNAP, 1.375 MTG HOLE
3
2
1112.00324.00
WELDMENT, DISPENSE VALVE BRACKET, CBS-70's
4
15
1083.00011.00
WASHER, #8 SCREW SIZE, INTERNAL TOOTH LOCK
5
23
1084.00006.00
NUT, 8-32 18-8 HEX MACHINE SCREW
6
6
1031.00033.00
LOCKNUT, 3/8"-18 NPT THREAD
7
2
1031.00043.00
FITTING BARB, 90° ELBOW,.3/8 HOSE ID X 3/8 MPT
8
1
1065.00004.00
CONNECTOR, COPPER LUG SLU-70
9
9
1083.00021.00
WASHER, SPRING LOCK, 1/4" SCREW, 18-8 SS
10
17
1084.00017.00
NUT, HEX, 1/4"-20
11
2
1033.00002.00
FITTING, BYPASS VALVE, CBS-70'S
12
4
1013.00083.00
LOCKNUT, 1"-14 THREAD
13
2
33023
FITTING BREW ORIFICE
14
2
33020
FITTING BY-PASS ORIFICE
15
4
86009
SPACER, BY-PASS VALVE, CBS-70'S
16
2
57029
VALVE, DISPENSE, BREW, CBS-70'S
17
2
57031
VALVE, BY-PASS, DSV11, 120V/60Hz
18
8
1083.00016.00
WASHER, #8 SCREW SIZE, FLAT
19
2
52023
TERMINAL BLOCK
20
16
1029.00018.00
NUT, #6 KNURLED THUMB
21
1
52051
THERMINAL BLOCK, CURTIS T4
22
1
52049
TERMINAL BLOCK, 2 POLE
23
2
52027
BREAKER CIRCUIT, 10A, 120V
24
2
86013
SNAP IN PLUG, 7/16" ID, SS
25
2
102312
ASSEMBLY, COLD WATER VALVES, CBS-70'S
26
2
1031.00049.00
FITTING, ELBOW 90° EXTRUDED , 3/8 FPT
27
2
1031.00025.00
FITTING, BARB, 1/2 HOSE ID X 3/8 NPT
28
2
31101
FITTING, BARB, 90º ELBOW, 1/2 HOSE ID X 3/8 MPT
29
8
15004
STANDOFF, 1/4" HEX, 2.25"LG.
30
2
102347
WELDMENT, ELECTRIC TUBE, CBS-70'S, 18"LG.
31
2
102348
WELDMENT, ELECTRIC TUBE, CBS-70'S, 28"LG.
32
2
108022
ASSEMBLY, BOARD CONTROL AND SOFTWARE, CBS-70'S, 120VAC
33
8
1082.00017.00.
SCREW, TRUSS HD. PHIL. MACHINE, # 6-32 X 1/2 LG
34
1
104079
TANK ASS'Y., 3 X 10kW/240VAC, CBS-70'S, LEFT
35
1
1104.00076.00
TANK ASS'Y., 3 X 10kW/240VAC, CBS-70'S, RIGHT (see figure 4)
36
1
45034
OVERLAY, CBS-72A, PUNCHED HOLES
37
2
102241
ASSEMBLY, READY LAMP SWITCH, CBS-70'S
38
2
102235
ASSEMBLY, POWER SWITCH, CBS-70'S
39
2
102237
ASSEMBLY BREW SWITCH, CBS-70'S
40
2
102238
ASSEMBLY, STOP SWITCH, CBS-70'S
41
2
102236
ASSEMBLY, RINSE SWITCH, CBS-70'S
42
2
32059
COLD WATER TUBE, 3/8"OD X 37.875 LG, CBS-70'S
43
1
52085
TRACK, CONTACTOR MOUNTING, 6" LG
44
1
52084
CONTACTOR, 65A, INDUCTIVE, 100A RESISTIVE, 120V COIL, 3-POLE
45
6
1052.00006.00
RELAY, OMRON, 120V, 1/2HP
46
2
1112.00332.00
WELDMENT SPRAY PAN BY-PASS, CBS-70'S
47
2
1102.00253.00
ASSEMBLY DRAWER, CBS-70'S (see figure 6)
48
2
B00962501
BREW BASKET ASSEMBLY, CBS 70'S (see figure 5)
49
2
25050
VENT TUBE, .375"ID X .655"OD X 13.5"LG.
50
8
1086.00010.00
CLAMP, WORM DRIVE, 7/16" - 25/32"
51
2
25054
BREW VALVE TUBE, .625"ID X .965"OD X 8.625"LG
52
4
086.00042.00
WORM DRIVE CLAMP 11/16" - 1 1/4"
53
2
25053
BY-PASS TUBE, .500"ID X .800"OD X 3.375"LG.
54
2
25051
DRAIN TUBE, 3/8"ID X 5/8"OD X 10.0"LG
55
4
1086.00002.00
CLAMP, HOSE, SIZE "G" NYLON
56
1
86046
PLUG, NYLON FINISHING LOCKING, 0.625" MOUNTING
57
2
1102.00260.00
ASSEMBLY, THERMAL CIRCUIT BREAKER, 152°C
58
2
01256
COVER, TOP, CBS-72A
59
2
002304
WELDMENT, CONTROL COVER, CBS-72
60
2
1001.00209.00
COVER, VENT, CBS-70'S
61
1
01262
COVER, FRONT, CBS-72A
62
20
82006
SCREW, #10-32 X 3/8" PHIL. TRUSS HD.
63
8
1073.00012.00-3
BALL BEARING ROLLER, BRUSHED FINISH
64
8
1073.00012.00-4
SCREW, HEX FLAT HD., 1/4-20 x 1" LG.
65
2
102422
DRAWER SLIDE ASSY, LEFT, CBS-70'S
66
2
102423
DRAWER SLIDE ASSY, RIGHT, CBS-70'S
67
12
1064.00020.00
SPLIT BOLT HEATER LUG, 10kW/240V
68
2
1046.00044.00
LABEL, TANK DRAIN
69
1
1046.00035.00
LABEL, WARNING "TO REDUCE RISK OF ELECTRIC SHOCK OR FIRE"
70
1
1044.00003.00
LABEL GROUND
