Go to fetco.com for the latest versions of all information Page 3 CBS-7000 Series Brewers & Dispensers P186 JANUARY 2020
Electrical Configuration and Brewing Efficiency
CBS-71A & AC 6.0 gallons per batch (max 5 per hour)
CBS-72A & AC 6.0 gallons per batch (max 5 per hour-per side)
Heater
Voltage
Maximum
Gallons per Hour
Model
SKU.
Configuration
Connection
Phase
Wires
KW
Amp draw
Maximum: 36
CBS-71A (-1) C71017 3 X 5 KW 120/208 3 ph. 4+ground 11.5 33.0
CBS-71AC (-1)
C71018
120/220
3 ph.
4+ground
13.3
36.0
18-24
120/240
3 ph.
4+ground
15.2
37.9
CBS-71A (-2) C71027 3 X 10 KW 120/208 3 ph. 4+ground 22.7 64.3
CBS-71AC (-2) C71028 120/220 3 ph. 4+ground 26.3 70.3 36
120/240
3 ph.
4+ground
30.2
74.0
CBS-71A (-3) C71037 3 X 10 KW 120/480 3 ph. 4+ground 30.2 37.9 36
CBS-71AC (-3)
C71038
3 X 10 KW
120/480
3 ph.
4+ground
30.2
37.9
“A” suffix is stationary counter mount; “AC” is mounted on a stand for use with a mobile cart. otherwise, the versions are identical units
The differences in “A” and “AC” are the counter or stand upon which the unit is placed.
Based on standard factory settings:
7 minute brew time, 200°F water
No drip delay
CBS-71A and CBS-72A stationary six gallon gourmet brewer CBS71 A & CBS-72A shown on optional A019 & A020 counter CBS-71AC & CBS-72AC shown with stand for use with mobile dispensers
CBS-71A & 72A shown with optional LBD-6 dispensers-purchase separately item D019 CBS-71AC & 72AC shown with optional LBD-6 mobile dispensers-purchase item D020
Heater
Voltage
Maximum
Gallons per Hour
Model
Configuration
Connection
Phase
Wires
KW
Amp draw
Maximum: 60
CBS-72A (-1)
C72017
3 X 5 KW
120/208
3 ph.
4+ground
11.6
33.7
CBS-72AC (-1)
C71018
on each side
120/220
3 ph.
4+ground
13.4
36.7
24-36
With Power Management
120/240
3 ph.
4+ground
15.3
38.6
CBS-72A (-2)
C72027
3 X 5 KW
120/208
3 ph.
4+ground
22.8
65.0
CBS-72AC (-2)
C71028
on each side
120/220
3 ph.
4+ground
26.4
71.0
36-42
Without Power Management
120/240
3 ph.
4+ground
30.3
74.7
CBS-72A (-3)
C72037
3 X 10 KW
120/208
3 ph.
4+ground
22.8
65.0
CBS-72AC (-3)
C72038
on each side
120/220
3 ph.
4+ground
26.4
71.0
54-60
With Power Management
120/240 3 ph. 4+ground 30.3 74.7
CBS-72A (-4) C72047 3 X 10 KW 3+ground
CBS-72AC (-4)
C72048
on each side
120/480
3 ph.
(plus 120V
30.3
37.9
60
With Power Management Cord & plug)
CBS-72A (-5)
C72057
3 X 10 KW
3+ground
CBS-72AC (-5) C72058 on each side 120/480 3 ph.
(plus 120V
60.3 74.7 60
Without Power Management Cord & plug)
-Each CBS-72 is actually two separate brewers in one body. Each side has a separate water tank and 3 heaters.
-The power management feature allows only one side of the brewer to heat at any given time, which limits the total
amperage required for operation. Power management option must be installed by factory.
Based on standard factory settings:
7 minute brew time, 200°F wa
ter
No drip delay
