Go to fetco.com for the latest versions of all information Page 19 CBS-7000 Series Brewers & Dispensers P186 JANUARY 2020
ITEM #
QTY
PART #
DESCRIPTION LBD-6 Drawing No. 1101.00309.00
1
1
1111.00074.00
WELDMENT, BODY, LBD-6
2
1
1112.00429.00
WELDMENT, GAUGE HOUSING, LBD-6
3
1
1087.00002.00
RIVET, BLIND DOMED, 5/32" DIA X .285 LG, SS
4
1
1022.00100.00-3
INSULATING, BOTTOM INSERT, LBD-6
5
1
1022.00100.00-1
INSULATING, BOTTOM, LBD-6
6
1
1102.00331.00
LINER ASSEMBLY, LBD-6
7
1
1013.00020.00
LOCKNUT, SHANK, 3/4-20
8
1
1102.00341.00
ASSEMBLY SHANK, 1 1/2 GAL. CONTAINER, LBD-6
9
1
1071.00014.00
WASHER, 79E, SIGHT GAUGE
10
1
1021.00026.00
TUBE, SIGHT GAUGE, LBD-6
11
1
1071.00016.00
WASHER, 80LH, SIGHT GAUGE
12
1
1071.00023.00
CAP, SHIELD #77-3
13
1
1071.00054.00
PLUG, SIGHT GAUGE VENT
14
1
1071.00012.00
C-RING, FOR TOMLINSON FAUCET
15
1
1012.00002.00
NUT, FAUCET UNION TPD/HWB
16
1
1071.00018.00
FAUCET, ES, COMPLETE, BLK HANDLE, "FETCO"
17
2
1022.00100.00-2
INSULATING, SIDE, LBD-6
18
1
1102.00332.00
ASSEMBLY, COVER, LBD-6
19
8
1087.00009.00
RIVET, BLIND SEALING, Ø3/16" BODY
20
4
1003.00040.00
LOCK, SLIDE, COVER, LBD-6
21
1
1112.00417.00
WELDMENT, FUNNEL COVER, LBD-6/18/24
22
1
1102.00318.00
BEAD CHAIN ASSY, FUNNEL COVER, LBD-18/24
23
1
1072.00009.00
BLACK KNOB, #8-32 x 3/8 DP. FEM. INSERT (FI-1)
24
4
1083.00036.00
WASHER, FLAT 5/16"
25
4
1072.00011.00
KNOB, COVER, LBD-6
26
1
1046.00045.00
CAUTION "HOT SURFACE"
ITEM #
QTY
PART #
DESCRIPTION LBD-6 cover Drawing No. 1102.00332.00
1
1
1004.00045.00
COVER TOP, LBD-6 DISPENSER, FORMED
2 1
1023.00267.00
FUNNEL, DISPENSER, 6 GAL.
3
1
1024.00087.00
"O"-RING, DASH #214, BUNA N (1.0"ID x 1 1/4"0D)
4
4
1082.00018.00
SCREW, TRUSS HD. PHIL. SM, #8 X 1/2 LG.
5
1
1025.00117.00
DOUBLE COATED TAPE, 1/2" W x 44" LG
6
1
1022.00100.00-4
INSULATING, TOP COVER, LBD-6
7
1
1004.00046.00
COVER BOTTOM, LBD-6 DISPENSER, FORMED
8
1
1024.00088.00
GASKET, COVER, LBD-6
9
1
1013.00114.00
SCREW, LBD-6 COVER, VENT
10
1
1084.00044.00
LOCKNUT, NYLON INSERT, 5/16-18
ITEM #
QTY
PART #
DESCRIPTION LBD-6 liner Drawing No. 1102.00331.00
1
1
1113.00015.00
WELDMENT, LINER, LBD-6
2
1
1024.00086.00
GASKET, LBD-6 LINER, 43.25" LG
3
1
1112.00434.00
WELDMENT, TOP, LBD-6
4
8
1003.00291.00
BRACKET, GASKET HOLDER, LBD-6/18/24
5
4
1013.00104.00
HANDLE, STAND-OFF SMALL
6
2
1112.00406.00
WELDMENT HANDLE, TOP, LBD-6
7
4
1083.00021.00
WASHER, 1/4" SCREW SIZE, SPRING LOCK
8
4
1082.00105.00
SCREW, HEX HD., 1/4-20 X 3/4"LG
ITEM #
QTY
PART #
DESCRIPTION LBD-6 cart Drawing No. 1101.00311.00
1
1
1111.00076.00
WELDMENT, LBD-6, SERVING CART
2
1
1073.00017.00
CASTER, SWIVEL, LBD-6
3
14
1083.00036.00
WASHER, FLAT 5/16"
4
8
1083.00037.00
WASHER, SPRING LOCK, 5/16' SCREW, 18/8 SS
5
10
1084.00038.00
NUT, HEX, 5/16-18 SCREW, 18-8 SS
6
1
1014.00010.00
BALANCE WEIGHT
7
2
1073.00015.00
WHEEL, CASTER, NON SWIVEL, LBD-6C
8
1
1082.00104.00
SCREW, HEX HD., 3/8-16 x 12" LG., ZINC PLTD.
9
1
1083.00022.00
WASHER, 3/8" SCREW SIZE, FLAT
10
1
1083.00020.00
WASHER, SPRING LOCK, 3/8 SCREW, 18-8 SS
11
1
1084.00040.00
NUT, HEX, 3/8-16 SCREW, 18-8 SS
12
1
1112.00430.00
WELDMENT, SINK, LBD-6, SERVICE CART
13
1
1001.00318.00
DRIP TRAY, LBD-6, SERVICE CART
14
2
1083.00039.00
WASHER, SPRING LOCK, 5/16 SCREW, 18-8 SS
15
4
1013.00104.00
HANDLE, STAND-OFF SMALL
16
4
1083.00021.00
WASHER, SPRING LOCK, 1/4" SCREW, 18-8 SS
17
4
1082.00105.00
SCREW, HEX HD., 1/4-20 X 3/4"LG.
18
2
1112.00407.00
WELDMENT HANDLE, FRONT, LBD-6
