Go to fetco.com for the latest versions of all information Page 21 CBS-7000 Series Brewers & Dispensers P186 JANUARY 2020
ITEM #
QTY
PART #
DESCRIPTION LBD-18 Drawing No. 1101.00300.00
1
1
1111.00073.00
WELDMENT, LBD-18
2
2
1003.00292.00
INSERT, CASTER CHANNEL
3
2
1073.00014.00
CASTER, SWIVEL, LBD-18 & 24
4
24
1083.00036.00
WASHER, FLAT 5/16"
5
16
1083.00037.00
WASHER, SPRING LOCK, 5/16' SCREW, 18/8 SS
6
18
1084.00038.00
NUT, HEX, 5/16-18 SCREW, 18-8 SS
7
2
1073.00013.00
CASTER, NON SWIVEL, LBD-18 & 24
8
2
1073.00015.00
WHEEL, CASTER, NON SWIVEL, LBD-6C
9
2
1001.00294.00
COVER, BUMPER MODIFIED, LBD-18/24
10
2
1087.00008.00
CLEVIS PIN W/HAIRPIN COTTER, 3/8 DIA. x 2 1/2" LG.
11
2
1013.00098.00
STAND OFF, HANDLE, LBD-18/24 GAL
12
2
1083.00021.00
WASHER, SPRING LOCK, 1/4" SCREW, 18-8 SS
13
2
1082.00099.00
SCREW, HEX HD., 5/16-18 X 1"LG.
14
1
1112.00408.00
WELDMENT HANDLE, FRONT, LBD-18/24 GAL
15
1
1112.00414.00
WELDMENT, LINER SUPPORT, 24 GAL.
16
3
1022.00099.00-2
INSULATING, BOTTOM, LBD-18
17
1
1022.00099.00-3
INSULATING, BOTTOM W/CUT, LBD-18
18
2
1022.00099.00-1
INSULATING, SIDE, LBD-18
19
1
1102.00315.00
LINER ASSEMBLY, LBD-18
20
16
1087.00009.00
RIVET, BLIND SEALING, Ø3/16" BODY
21
1
1112.00411.00
WELDMENT, GAUGE HOUSING, LBD-18
22
2
1087.00002.00
RIVET, BLIND DOMED, 5/32" DIA.,SS
23
1
1086.00043.00
BUSHING, SNAP, .750 MTG HOLE
24
1
1112.00419.00
WELDMENT, SIGHT GAUGE, LBD's
25
1
1084.00039.00
HEX NUT, 1/2"-20 X 7/16"THK.
26
3
1071.00014.00
WASHER, 79E, SIGHT GAUGE
27
2
1013.00035.00
CAP, GAUGE VENT
28
1
1021.00025.00
TUBE, SIGHT GAUGE, LBD-18
29
1
1071.00016.00
WASHER, 80LH, SIGHT GAUGE
30
1
1071.00023.00
CAP, SHIELD #77-3
31
2
1086.00044.00
BUSHING, SNAP, Ø1.125 MTG HOLE
32
2
1013.00102.00
SHANK, SIDE FAUCET, LBD-18/24
33
2
1071.00012.00
C-RING, FOR TOMLINSON FAUCET
34
2
1012.00002.00
NUT, FAUCET UNION TPD/HWB
35
2
1071.00018.00
FAUCET, ES, COMPLETE, BLK HANDLE, "FETCO"
36
2
1022.00096.00
INSULATION, FAUCET, LBD-18
4
1
1112.00415.00.
WELDMENT, SINK TRAY, SERVICE CART, 18/24 GAL
38
2
1083.00039.00
WASHER, SPRING LOCK, 5/16 SCREW, 18-8 SS
39
1
1001.00296.00
DRIP TRAY, SERVICE CART, 18/24 GAL.
40
1
1102.00319.00
ASSEMBLY, COVER, LBD-18/24 GAL.
41
4
1003.00041.00
LOCK, SLIDE, COVER, LBD-18, 24
42
4
1072.00010.00
HAND KNOB, TYPE K, 5/16-18 THREAD
43
2
1046.00045.00
CAUTION "HOT SURFACE"
ITEM #
QTY
PART #
DESCRIPTION COVER LBD-18/LBD-24 Drawing No. 1102.00319.00
1
1
1112.00416.00
WELDMENT, COVER TOP, LBD-18/24
2
2
1023.00254.00
DISPENSER, FUNNEL, 18/24 GAL.
3
6
1082.00018.00.
SCREW, TRUSS HD. PHIL. SM, #8 X 1/2 LG
4
2
1021.00024.00
COVER, SPACER, LBD-18/24
5
2
1013.00104.00
HANDLE, STAND-OFF SMALL
6
1
1112.00409.00
WELDMENT HANDLE, COVER, LBD-18/24
7
1
1022.00098.00-4
INSULATING, TOP COVER, LBD-24
8
1
1004.00044.00
COVER BOTTOM, MACHINED, LBD-18/24
9
2
1082.00101.00
SCREW, HEX. HD., 1/4-20 X 3" LG.
10
2
1013.00105.00
BUSHING, FUNNEL
11
1
1024.00079.00
GASKET, DISPENSER COVER, LBD-18/24
12
2
1112.00417.00
WELDMENT, FUNNEL COVER, LBD-6/18/24
13
2
1102.00318.00
BEAD CHAIN ASSY, FUNNEL COVER, LBD-18/24
14
3
1072.00009.00
BLACK KNOB, #8-32 x 3/8 DP. FEM. INSERT (FI-1)
15
1
1025.00113.00
DOUBLE COATED TAPE, 1/2" W x 69.5 LG.
16
2
1013.00114.00
SCREW, LBD-6 COVER, VENT
17
2
1084.00044.00
LOCKNUT, NYLON INSERT, 5/16-18
ITEM #
QTY
PART #
DESCRIPTION LINER LBD-18 Drawing No. 1102.00315.00
1
1
1112.00412.00
WELDMENT, TOP, SERVICE CART, 18/24 GAL.
2
1
1024.00078.00
GASKET, LINER, LBD-18/24 GAL., 68.63" LG.
3
1
1113.00013.00
WELDMENT, LINER, LBD-18
4
1
1001.00288.00
LOCATOR, TOP, SERVICE CART, 18/24 GAL.
5
2
1087.00009.00
RIVET, BLIND SEALING, Ø3/16" BODY
