Description Drawing 1101.00579.00, CBS-1242
NUT, HEX LOCKWASHER, #8-32, 18-8 ST. STL.
FRONT PANEL ASSY, DOUBLE, PLUS SERIES
SCREW, #6 X 3/8 LG, TRUSS HD PHIL, SHEET MTL
SCREW, # 8-32 X 5/8, FLAT HD, PH, 18-8 SS
ELECTRICAL COMPONENT LATTICE, NEXT GEN XV+
ELECTRICAL MOUNTING LATTICE, COMMON
EUROSTRIP HE16 TERM. BLOCK, 4 POLE, 63 AMP, 18-8 AWG
SCREW, # 8-16 x 1” PAN HD PHIL, THREAD FORMING, FOR PLASTICS, 18-8 SS
SWITCH, POWER, DOUBLE POLE, 16A, 125/250 VAC
SOLENOID VALVE, 5.5L/min, 180 DEG, 24VDC
SCREW, PAN HD. PHIL. MACH., M4x10 ZINC-PLATED
POWER SUPPLY, 90-264VAC/24VDC, 2.25A
SCREW, #6 X 5/8, TRUSS HD PHIL, SHEET MTL
QUICK CONNECT SPRAY HEAD ASSEMBLY,30/40’S, BASIC
O-RING, 3 15/16” x 3/32” CS, DASH # 154, BUNA-N, DURO-A50
O-RING, 1 3/16” OD X 1 1/16” ID X 1/16” TH, BYPASS SEAL
VENT INSERT, QUICK CONNECT
O-RING, 13/16”OD X 11/16”ID X 1/16” TH, FOR QUICK CONNECT
WASHER, #10 SCREW W/NEOPRENE-BONDED SEAL
NUT, 8-32 18-8 HEX MACHINE SCREW
VENT TUBE, CBS- EXTRACTOR SERIES
BUSHING, SNAP, 1” MOUNTING HOLE
ADAPTER ASSY, ¾” BSP x ¼” NPT x 3/8” TUBE
GROUND LUG CONNECTOR, 14-2 AWG, ALUMINUM
NUT, CLIP ON (J-NUT), #6-32, 22-20 GA., BLK-PH FINISH
TUBE, 9/16”OD X 5/16”ID X 25.00”LG
CLAMP, ¾” MAX TUBE OD FLOW CONTROL
UNICLAMP, 15.9 HOSE OD CLAMP
WELDMENT FRONT COVER, CBS-2240
COVER, UPPER BASE, CBS-2232/42
SCREW, TRUSS HD. PHIL. MACHINE, # 6-32 X ½ LG.
LABEL, WARNING “TO REDUCE RISK OF ELECTRIC SHOCK OR FIRE”
LABEL, CSD WARNING, 1.5” X 5.0”
BLACK EXTRACTOR PLUS LABEL, LASER ENGRAVED
WIRE HARNESS, CBS-1240/50, LOW AMP, UNIVERSAL
HARNESS ADDITION, LOW AMP, CBS-1232/42, UL
TANK ASSEMBLY, CBS-2242, 2 X 3KW/240VAC
TANK ASSEMBLY, CBS-2242, 2 X 2.3KW/240VAC
TANK ASSEMBLY, CBS-2242, 2 X 4KW/240VAC
HARNESS HIGH AMP, CBS-2232/42/51, UL
WIRE HARNESS ADDITION, HIGH AMP, EMI FILTER, 2-POLE, CE
BREW BASKET ASSY, BLACK, 13” X 5”, 0.218” DIA HOLE, BROWN PLUG
BREW BASKET ASSY, 13” X 5”, .218 DIA HOLE, BLACK
GROMMET, SILICONE, W/ POSITION TABS
FITTING VENT, ELBOW, .375” X .375”, SELF POSITIONING
TUBE, 304SS, .625OD X .065 WALL X 9-1/4” LG.
HOT WATER INSERT, MANUAL FAUCET
FAUCET, HOT WATER, PSC-BR-8, WITH FLAT AND STEM
JAM NUT, ½-20 UNF, NICKEL PLATED BRASS
TUBE, 9/16”OD X 5/16”ID X 13.00”LG
HOT WATER INSERT, NO FAUCET
ORIFICE INSERT, QUICK CONNECT, 3/16” HOLE
VALVE ASSEMBLY, COMPLETE, NG, DELTROL
BYPASS L-TUBE, SILICONE, 2200 SINGLE SERIES
PLUG INSERT, QUICK CONNECT
ASSEMBLY, BB LOCKER, 24VDC
BRACKET, BREW BASKET LOCK COVER
WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
LEG, FLANGE FOOT, 4.0” HIGH
CONNECTOR, CLAMP, NON-METALLIC CABLE, ¾”
SKINTOP, ¾” NPT, 0.354” - 0.630” DIA CABLE, BLK
LOCKNUT, SKINTOP, ¾” NPT, BLACK HEX
LABEL EQUIPOTENTIALITY, CE
EMI FILTER, THREE LINE 30A, 250/440VAC EXPORT ONLY
NUT, HEX, #6-32 MACHINE SCREW
WELDMENT BRACKET TERMINAL BLOCK, 3 POLE
EUROSTRIP HE10 TERM. BLOCK, 3 POLE, 50AMP, 18-8 AWG
SCREW, PHILLIP HD., 8-32 THREAD
