33
GETTING TO KNOW YOUR CAR
DIRECTIONAL AND
ADJUSTABLE AIR VENTS
fig. 33
The vents can be rotated upwards
or downwards.
A - Control for adjusting air flow:
turned to ¥ vent open.
turned to ç vent closed.
B - Control for directing air flow.
C - Fixed vent for side windows.
CONTROLS fig. 34
A - Air temperature knob (mixing
hot and cold air).
B - Fan knob .
C - Air distribution knob.
D - Air recirculation slider. This pre-
vents air from being taken in from the
outside.
HEATING
1) Air temperature knob A-fig. 34:
pointer in the red sector.
2) Fan knob B: pointer at required
speed.
3) Air distribution knob C: pointer at:
≤ to warm the feet and demist the
windscreen at the same time;
¥ to direct air to the central and
side vents;
μ to warm the feet and keep the
face cool (intermediate position);
w to heat when the outside tem-
perature is especially low: to send
most air to the footwell, close the
central and side vents;
- to rapidly demist the windscreen.
fig. 33
P4Q00047
fig. 34
P4Q00019
