Fiat 600 - Front Side Lihhts; Front Direction Indicators

93
IN AN EMERGENCY
3) replace the bulb and refit the bulb
holder A.
Front direction indicators
To replace the 12V-21W bulb:
1) release the clip A-fig. 17, work-
ing in the direction of the arrow;
2) remove the lens unit B-fig. 18
from the front;
3) the bulb holder C is connected to
the lens. Turn it slightly to remove;
4) remove the bulb D, pushing it in
slightly and turning it anti-clockwise at
the same time;
5) after changing the bulb, refit the
bulb holder onto the lens;
6) replace the lens unit in its seating
inserting the tabs E-fig. 19 in the
guides F to the side of the light;
7) refasten the clip A-fig. 17.
FRONT SIDE LIGHTS
To replace the 12V-5W bulb:
1) take out the bulb holder A-
fig. 15, turning slightly to release;
2) remove the bulb B-fig. 16;
fig. 16
P4Q01027
fig. 15
P4Q01026
fig. 17
P4Q01028
fig. 18
P4Q00108
fig. 19
P4Q00109
