Fiat Capron A461 - Opening the Pull-down Bed; Closing the Pull-down Bed; Bunk Bed Safety and Use

61Capron - 04-17 - CAP-0017-01EN
Living
7
Opening the pull-down bed:  Switch off the lamps on the underside of the pull-down bed.
 Push the driver's seat and the front passenger's seat all the way forward.
 Fold over the back cushion of the divan.
 Open the lock (Fig. 49,1).
 Use both hands to pull the pull-down bed down as far as it will go.
Closing the pull-down bed:
 Switch off the reading lamps in the pull-down bed.
 Loosen the retaining straps of the safety nets and lay the safety nets under
the mattress.
 Use both hands to push pull-down bed upwards as far as it will go.
 Make sure that the lock has engaged audibly.
Access ladder Always use the access ladder provided as standard to access the pull-down
bed.
Attaching:
 Hook the access ladder (Fig. 51,3) to the pull-down bed by attaching the
two hooks to the curved handle (Fig. 51,4).
Safety net The safety nets (Fig. 51,2) with the retaining straps are stored under the mat-
tress. Only use the safety nets if persons are already in the pull-down bed.
Setting up:
 Fasten the retaining straps (Fig. 51,1) to the holders on the ceiling.
7.9.3 Bunk bed
Depending on the model, the rear area is fitted with a bunk bed. The bunk bed
can also be used as a rear garage.
Fig. 51 Access ladder and safety net
X The maximum permitted bunk bed load is 100 kg.
X Only use the upper bunk bed if the safety guard is fitted.
X Never allow small children to remain in the bunk bed without supervision.
X But in particular with regard to small children less than 6 years of age,
users should ensure that they cannot fall out of the bunk bed.
X Use separate children's beds or travel cots suitable for children.
