Introduction
Technical specifications
Thanks for choosing Mini 6S FTTx Master from FiberFox. The Mini 6S with innovative design and
exquisite manufacturing technology gives customers unexperienced convenience.
Unprecedented splicing experience and new technology greatly reduces splicing and heating
time. Advanced estimate method and core alignment technique ensure the accuracy of splice loss
estimation. Its small size, compact design and reliable protection shell make it suitable for any
operating environment. Dynamic operation interface and automatic splice mod give the customers
grat convenience. For more information, please contact your local distributor or visit our website at
www.fiberfox.co.kr
This manual explains the features, specifications, operation, maintenance and warnings about Mini
6S. The primary goal of this manual is to make the user as familiar with the splicer as possiblse.
Camera High precision dual camera
Display 4.3” wide color reinforced LCD
Microscope
x150 : X&Y axis dual view
x300 : X axis single view
x300 : Y axis single view
Power Supply
Splicer
AC 100~240V
50~60HZ
DC9~14V
Li-ion Battery DC 11.1V
Data Capacity
Splice Mode
Factory pre-set 33ea
User Edit 34ea
Data Storage (Splicing result) 3,000ea
Splice Speed
SM FAST mode 7 Sec.
SM AUTO mode 9 Sec.
Heating
Oven
Applicable Sleeve
Standard : 20, 25, 30, 35, 40, 60mm
Custom : 4*32mm sleeve (For SOC)
Heating Time 8~900sec (Typical: 18Sec)
Cooling Time 0~ 180sec
Heat mode
Factory pre-set 9ea
User Edit 9ea
Heating block
Standard 1ea(Pre-installed)
SOC Customized 1ea(In Package)
Applicable
Fiber
Fiber count : Single core
Fiber Type : SM(ITU-TG.652)/ DS(ITU-TG.653)/ NZDS(ITU-TG.655)/
ITU-TG.657 / MM(ITU-TG.651)
Applicable
Cable
Fiber count : Single core fber in cable
Applicable diameter : 0.25mm / 0.9mm / 2.0mm / 2.4mm / 3.0mm
Applicable buffer Diameter
: Cladding diameter : 80~150µm, Coating diameter : 100~3,000 µm
Splice Loss
SM : 0.02dB
MM : 0.01dB
DS : 0.04dB
NZDS : 0.04dB
G.657 : 0.02dB
Reliability
Operating
Condition
Altitude 0~5,000M
Humidity 0~95%
Temperature -15~60
℃
Wind Speed 15m/s
Storage
Condition
Humidity 0~95%
Temperature
Splicer -40~80
℃
Battery -20~30 ℃
