AN5116-06B/AN5516-06/AN5516-04 Optical Line Terminal Equipment Hardware Description
Table 3-50 Indicator LEDs
Identifier
Meaning
Color Status
Description
ACT
Working
indicator
LED
Green
ON
The card is working normally.
Blinking slowly
The card is being initialized or the software is being
started. The communication link between the active
and standby cards is not set up.
Blinking quickly
The card is receiving a configuration command or
the communication link between the active and
standby cards is being set up.
OFF
The card is not powered on or the software is not
started.
ALM
Alarm
indicator
LED
Red
ON
The card has alarms for fiber disconnection, light
leakage, and absence of optical module at the PON
port, or the communication between the active and
standby cards is interrupted.
OFF
The card is working normally.
LINK1～8
Port status
indicator
LED
Green
ON
The port is connected to an ONU at the far end, and
the ONU has been authorized.
OFF
The port is not connected to an ONU at the far end,
or the far-end ONU is not authorized.
Technical Specifications
Item Specification
Network standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ah、IEEE
802.1D, IEEE 802.1p, IEEE 802.1Q, ITU-T G.703, ITU-T G.
984.1, ITU-T G.984.2, ITU-T G.984.3, ITU-T G.984.4, ITU-T G.
987、ITU-T G.987.1, ITU-T G.987.2, ITU-T G.987.3, ITU-T G.
988, IETF RFC 2236, and TR-156, etc.
Switching mode
Store-and-forward
Supported MAC address
quantity
250 k
Maximum split ratio
1:256
Maximum quantity of T-
CONTs
2048
Bandwidth allocation
granularity
64 kbit/s
Optical fiber connector
SC/PC
Network cable
G.652 single-mode fiber
