AN5116-06B/AN5516-06/AN5516-04 Optical Line Terminal Equipment Hardware Description
Item
Specification
Output optical power
1490 nm: 2 dBm to 7 dBm
1577 nm: 2 dBm to 5 dBm
1490 nm: 2 dBm to 7 dBm
1577 nm: 2 dBm to 5 dBm
Optical fiber connector
type
SC/PC SC/PC
Transmission distance 20 km 20 km
Receiving sensitivity
-29.78 dBm
1270 nm: -28 dBm; 1310 nm: -29.78 dBm
Overload optical power
-9.38 dBm
1270 nm: -6 dBm; 1310 nm: -9.38 dBm
Extinction ratio
1490 nm: ＞ 9 dB, 1577 nm: ＞ 6 dB 1490 nm: ＞ 9 dB, 1577 nm: ＞ 6dB
4.4 GPON Optical Module
Item
Specification
Module code
2.5/1.25G-20km-GPON
OLT-SFP (CLASS B+)
2.5/1.25G-20km-GPON
OLT-SFP (CLASS C+)
2.5/1.25G-20km-GPON
OLT-SFP (CLASS C++)
Optical module type
CLASS B+ CLASS C+ CLASS C++
Wavelength range
Tx: 1480 nm to 1500 nm
Rx: 1260 nm to 1360 nm
Tx: 1480 nm to 1500 nm
Rx: 1260 nm to 1360 nm
Tx: 1480 nm to 1500 nm
Rx: 1260 nm to 1360 nm,
1290 nm to 1330 nm, 1280
nm to 1360 nm
Encapsulation mode
SFP SFP SFP
Rate
Tx: 2.488 Gbit/s
Rx: 1.244 Gbit/s
Tx: 2.488 Gbit/s
Rx: 1.244 Gbit/s
Tx: 2.488 Gbit/s
Rx: 1.244 Gbit/s
Output optical power
2.5 dBm to 5 dBm (room
temperature)
4 dBm to 7 dBm (room
temperature)
5.5 dBm to 10 dBm (room
temperature)
Optical fiber connector
type
SC/PC SC/PC SC/PC
Transmission distance 20 km 20 km 20 km
Receiving sensitivity
-29 dBm (room
temperature)
-31 dBm (room
temperature)
-31 dBm (room
temperature)
Overload optical power
-8 dBm -12 dBm -12 dBm
Extinction ratio
＞ 8.2 dB ＞ 8.2 dB ＞ 8.2 dB
146 Version: C
