Fike EIV - EIV Specifications

EXPLOSION ISOLATION VALVE
INSTALLATION & OPERATION MANUAL
January, 2015 Document P/N: E06-017-1 (Rev 2) Page: 10
2.7 EIV SPECIFICATIONS
TABLE 1 – EIV SPECIFICATIONS (Ref. Figures 8 and 9)
EIV
SIZE
STUD
QTY
TORQUE
(FT-LBS.)
Dynamic load
lbf
WT
lbs.
Ø P
Ø BC
Ø F
2"
8
55
300
75
2
4.75
5/8-11
3"
8
55
800
145
3
6.00
5/8-11
4"
16
55
900
150
4
7.50
5/8-11
6"
16
65
1000
220
6
9.50
3/4-10
8"
16
65
1000
330
8
11.75
3/4-10
10"
24
110
900
480
10
14.25
7/8-9
12"
24
110
2000
600
12
17.00
7/8-9
14"
24
135
2500
830
14
18.75
1-8
16"
32
135
2700
960
16
21.25
1-8
18"
32
150
2900
1,135
18
22.75
1 1/8-8
20"
40
150
3400
1,530
20
25.00
1 1/8-8
24"
40
150
3800
1,820
24
29.50
1 1/4-8
EIV
SIZE
A
B
C
D
E
T
2"
5 5/8
12 1/2
32 1/2
5 1/2
9 1/2
3 1/2
3"
9 1/2
19 1/2
41
9 1/4
14
4 1/2
4"
9 1/2
19 1/2
41
9 1/4
14
4 1/2
6"
12 3/4
26 1/4
50
11 1/4
14 3/4
4 1/4
8"
15 3/4
32 1/4
58
13 3/4
17 1/2
4 1/2
10"
19
38 1/2
64 1/2
16 1/4
20
4 7/8
12"
26 3/4
47 1/4
77
21
28 1/4
8 1/4
14"
30 3/4
54 1/2
87
23
29 1/2
8 1/4
16"
33 3/4
60 1/2
95
25
32 1/4
8 1/4
18"
37 3/4
69 1/2
106
28
37
8 1/4
20"
41 1/4
74
114
30 1/2
38
6 3/4
24"
48 1/4
91 1/2
138
36
45
6 3/4
NOTE: All specifications are subject to change and should be used for reference only.
Stud quantity is 2X hole quantity based on ASME B16.5 for ANSI 150 flanges.
