REPLACING THE DUST PRE-FILTER FIL-P-MC-426
! Replacement filters can be purchased from: www.filtrabox.com or call (514-
840-9696 ext. 102)
! Important Note: The Filter Alignment Rings must be centered correctly into
each filter. They should fit inside both filters when installed correctly.
! To avoid any risk of electrical discharge, turn off and unplug the Filtrabox
before doing any activities that require disassembly of the unit.
1. Loosen both Strap Clamps on the Lid by pressing the lever on the clamps. Unhook the Strap
Clamps and remove the Lid by lifting it straight up off the assembly.
2. Set aside the topmost Filter Alignment Ring.
3. Remove and replace the old Pre-Filter and ensure that the new one is centered correctly onto
the HEPA Filter and that it is oriented the right way up on the next Filter Alignment Ring.
4. Ensure that the new Pre-Filter is the right side up by following the label.
5. Replace the topmost Filter Alignment Ring that was set aside earlier onto the new Pre-Filter.
6. Replace the Lid back onto the machine and tighten both Strap Clamps back onto the hooks.
7. Check the Machine Diagram on page 4 if necessary.
REPLACING THE DUST HEPA FILTER FIL-P-MC-416
! Replacement filters can be purchased from: www.filtrabox.com or call (514-
840-9696 ext. 102)
! Important Note: The Filter Alignment Rings must be centered correctly into
each filter. They should fit inside both filters when installed correctly.
! To avoid any risk of electrical discharge, turn off and unplug the Filtrabox
before doing any activities that require disassembly of the unit.
1. Loosen both Strap Clamps on the Lid by pressing the lever on the clamps. Unhook the Strap
Clamps and remove the Lid by lifting it straight up off the assembly.
2. Set aside the topmost Filter Alignment Ring, the Pre-Filter, and the next Filter Alignment Ring.
3. Remove and replace the old HEPA Filter and ensure that the new one is centered correctly onto
the Gas Filter and that it is oriented the right way up on the next Filter Alignment Ring.
4. Replace one of the Filter Alignment Rings (they are all the same) that was set aside earlier onto
the new HEPA Filter.
5. Replace the Pre-Filter and the topmost Filter Alignment Ring that were set aside earlier onto
the new HEPA Filter as well.
6. Ensure that the new HEPA Filter and Pre-Filter are the right side up by following the labels.
7. Replace the Lid back onto the machine and tighten both Strap Clamps back onto the hooks.
8. Check the Machine Diagram on page 4 if necessary.
