REPLACING THE OXY-CARBON GAS FILTER FIL-G-MC-406
! Replacement filters can be purchased from: www.filtrabox.com or call (514-
840-9696 ext. 102)
! Important Note: The Filter Alignment Rings must be centered correctly into
each filter. They should fit inside both filters when installed correctly.
! To avoid any risk of electrical discharge, turn off and unplug the Filtrabox
before doing any activities that require disassembly of the unit.
! Attention: The OXY-Carbon Gas Filter is HEAVY. The Filter weighs
approximately 20lbs. Take appropriate care and precaution when lifting.
1. Loosen both Strap Clamps on the Lid by pressing the lever on the clamps. Unhook the Strap
Clamps and remove the Lid by lifting it straight up off the assembly.
2. Set aside the three Filter Alignment Rings, the Pre-Filter, and the HEPA Filter.
3. Remove and replace the old Gas Filter and ensure that the new one is centered correctly onto
the Base Module.
4. Replace one of the Filter Alignment Rings (they are all the same) that was set aside earlier onto
the new Gas Filter and that it is oriented the right way up.
5. Replace the HEPA Filter and the next Filter Alignment Ring that were set aside earlier onto the
new Gas Filter and that it is oriented the right way up.
6. Replace the Pre-Filter and the topmost Filter Alignment Ring that were set aside earlier onto
the HEPA Filter and that it is oriented the right way up.
7. Ensure that all the Filters are the right side up by following the labels.
8. Replace the Lid back onto the machine and tighten both Strap Clamps back onto the hooks.
9. Check the Machine Diagram on page 4 if necessary.
