Fimap FS50 B-BT - Page 5

5
TECHNICAL DESCRIPTION UM
FS50 H FS50 HT FS50 B FS50 BT
Working width without side brush mm 500 500 500 500
Work capacity, up to m
2
/h 2275 2600 2275 2600
Maximum gradient % 5 10 5 10
Central brush dimensions mm 500x265 500x265 500x265 500x265
Debris hopper capacity l 40 40 40 40
Honda internal combustion engine HP 3 3 - -
Electric motor V - - 12 12
Electric motor W - - 600 600
Filtering surface m
2
2.5 2.5 2.5 2.5
Type of advance - mechanical - mechanical
Forward speed km/h 0÷3.5 0÷4 0÷3.5 0÷4
Machine length mm 1430 1430 1430 1430
Machine height mm 1000 1000 1000 1000
Machine width mm 660 660 660 660
Battery V/Ah - - 12/140 12/140
Battery compartment dimensions LxWxH 340x175x220 340x175x220 340x175x220 340x175x220
Battery weight kg - - 28.5 28.5
Machine weight (empty and without battery) kg 70 78 67 65
Machine weight in running order kg
70
78 95.5 93.5
Noise level (in compliance with IEC 704/1) dB (A) 74 74 68 68
Vibration level m/sq.sec. 1.2 1.2 0.12 0.12
