Fimco TR-20-EX - Pump Operations and Maintenance; Recommended Pump Practices (DO); Prohibited Pump Usage (DONT); Pump Troubleshooting

Page 6
Troubleshoong the Pump:
Motor does not run:
 Check for loose wiring connecon(s).
 Make sure the 'ON/OFF' switch in the lead wire assembly is in the
'ON' posion. “I" is the 'ON' posion and 'O' is the 'OFF' posion.
 Check for defecve pressure switch. Make sure you are connected to
a good 12 volt power source. Make sure any on/o switches are in
the 'on' posion.
 Remove the cap to the pressure switch. Pull both red wires o of
their terminals, and touch the two ends together. If your pump runs
when you do this, your pressure switch will need to be replaced.
 Check the fuse.
 Check for low voltage at the power supply.
Pump does not prime:
 Check for air leaks in supply line.
 Check for debris in the check valve assembly.
 Check for defecve check valve.
 Check for clogged strainer/lter.
 Check for cracks in the pump housing.
 Check for empty product supply.
Pump Model: 5277981
Available Replacement Parts
DO
 Clean and rinse your pump after each use with Fimco Tank
Neutralizer
 Winterize your pump or sprayer by rinsing, draining and
running RV Antifreeze through it before storing for the winter.
 Use clean water for your spray mixture
 Store inside a building when not in use.
DON’T
 Use to pump bleach.
 Use to pump petroleum products such as diesel fuel,
gasoline or kerosene
 Leave your pump sit with spray mixture in it for extended
periods
 Use dirty or unfiltered water for spraying
Pump Specifications
Current: 4.5 Amps @ 30 PSI
Check Valve: Viton
Wetted Parts Housing: Polypropylene
Diaphragm: Santoprene
Liquid Temperature: 130° F max.
GPM=Gallons Per Minute
PSI=Pounds per Square Inch
DC=Direct Current
Pulsang ow (surging):
 Check for defecve pressure switch.
 Check for leaks in the discharge line.
 Check for restricon in the discharge line.
 Check for debris in nozzle orice.
 Discharge hose may be too long.
 Check for clogged strainer.
Motor connues to run aer discharge is shut o:
 Check for empty product supply.
 Check for open bypass valve. (if equipped)
 Check for low voltage.
 Check for leak in discharge line.
 Check for defecve or dirty check valve.
 Check for defecve pressure switch.
