WARNING: When “Basic” electrodes are
being used, remove any residue left on the
electrode before welding. To do that, gently
tap the electrode on a metallic surface. (If
residue is left on an arc cannot be
generated).
9. WIRE LINER REPLACEMENT
In case of wire liner replacement please
follow carefully this instructions.
• Gun side: remove the gas nozzle (A).
•Unscrew the wire liner tip (B).
• Connector side (C): unscrew the terminal nut
(D, E) and grab the end of wire liner using a
pliers and start to extract the wire liner (F).
• Complete the liner substitution rescrewing the
covering nozzle (A).
Figure 9: wire liner replacement
• Complete the extraction of the wire liner (G)
• Insert the new liner and push up to end (H).
• Now rescrew the liner tip (B) on the gun.
A
B
C
D
E
F
G
H
