TM 230 - TM 260 - TM 300 - TM 350 - TM 320W
TM 360W - TM 420W - TM 500W - TM 650W
Instruction Manual

Questions and Answers

  • D
    David RossAug 17, 2025
    What to do if my Fimer TM360W cuts out after prolonged use?
    • E
      Emma Ramos DVMAug 17, 2025
      If the welder cuts out after prolonged use, it might have overheated, activating the thermal protection device. Allow the unit to cool down for at least 1-20 minutes.
  • T
    Theodore AdamsAug 20, 2025
    Why are my welds porous with Fimer TM360W Welding System?
    • M
      mpatelAug 20, 2025
      Porous welds can occur due to several reasons: * A build-up in the gas nozzle causing a lack of shielding gas, clean away build-up. * Incorrect torch angle. The air gap between the torch and the workpiece must be 5-10 mm. Ensure 60° torch angle. * Gas shortage, increase gas flow. * Damp workpieces, dry workpieces with hot-air gun or suchlike. * Welding Arc too long, shorten the arc.
  • J
    Jennifer HaleAug 22, 2025
    What to do if arc cut-out occurs with Fimer TM360W?
    • J
      Joseph ReyesAug 23, 2025
      Arc cut-out can be caused by: * Loose earth clamp grip, tighten clamp grip. * Short circuit between contact nozzle and gas hose, clean or replace contact nozzle and wire-feed nozzle.
  • R
    Richard AlvarezAug 26, 2025
    How to reduce excessive splashes from Fimer TM360W Welding System?
    • M
      matthew51Aug 26, 2025
      Excessive splashes can be due to: * Current being too high, decrease the current value. * Non-optimized inductance value, increase the inductance value. * Torch being too inclined, straighten the torch.
  • T
    theresa43Aug 28, 2025
    How to fix jerky wire feed on Fimer TM360W?
    • J
      Jeremy HarperAug 28, 2025
      Jerky or intermittent wire-feed can be caused by: * Faulty gas nozzle, replace it. * Scorched gas nozzle, replace it. * Dirt in wire-feeder roller groove, clean it. * Worn wire-feeder roller groove, replace it.
  • A
    Angela DaughertyAug 30, 2025
    How to improve penetration with Fimer TM360W Welding System?
    • E
      elizabethwheelerAug 31, 2025
      Insufficient penetration can happen if: * The current is too low, increase the current. * There is inconstant wire feeding, see the above paragraph. * Edges are too apart from each other. * Bevel is too small.
  • T
    Tanya DavidsonSep 2, 2025
    How to prevent hot cracks when welding with Fimer TM360W Welding System?
    • M
      Michael DillonSep 3, 2025
      Hot cracks can be caused by: * Damp workpieces, clean them. * Welding with very high heat supply, decrease the welding current. * Impure welding wire, change the welding wire. * Base material with high content of carbon, sulphur and other impurities.
  • R
    Ryan MontgomerySep 5, 2025
    What to do if the wire does not feed on my Fimer TM360W?
    • A
      Alexis HartmanSep 5, 2025
      If the wire does not feed when the wire-feeder roller rotates, check for: * Dirt on the tip of the wire-feeder, blow with compressed air, replace nozzle. * Excessive spool torque, loosen it. * Faulty torch, check wire-feeder liner.
  • V
    Veronica StoutSep 8, 2025
    How to resolve insufficient melting with Fimer Welding System?
    • J
      Jeffrey GallegosSep 8, 2025
      Insufficient melting can occur due to: * Abrupt movements of the torch, move the torch smoothly. * Non-optimized inductance value, change the inductance value. * Oxidized workpieces, clean them.
  • A
    aaronaguilarSep 12, 2025
    What causes breakages when using Fimer TM360W?
    • J
      Jennifer PhillipsSep 12, 2025
      Breakages can be caused by: * Unsuitable wire, change the type of wire. * Bad quality of the workpieces.

Summary

WARNING SYMBOLS

General Safety Warnings

Important safety precautions and general warnings for using the equipment.

WELDING OPERATION SAFETY INSTRUCTIONS

Personnel Protection

Safety measures for the welder and bystanders during operation.

Fire Prevention

Precautions to prevent fires during welding operations.

MIG WELDING

Power Supply Connection

Instructions for connecting the welding machine to the power supply.

Output Connections

How to connect welding cables and torch to the machine.

UNIT DESCRIPTION

Front View Components

Identification and description of front panel controls and connectors.

INSTALLATION OF THE WELDING WIRE

Wire Feeder Roller Adjustment

How to adjust wire feeder rolls for different wire diameters.

CONNECTION BETWEEN THE SEPARATE TROLLEY AND BASE

Connecting Power and Signal Cables

Procedure for connecting the trolley to the machine base.

CONNECTION OF THE GAS CYLINDER AND REGULATOR

Gas Handling and Safety

Steps and safety precautions for connecting gas cylinders.

MIG TORCH

Torch Maintenance

Checking and maintaining the welding torch for optimal performance.

PREPARING FOR THE WELDING

Final Checks Before Welding

Ensuring correct connections and polarity before starting welding.

WELDING PROCESS

Setting Welding Current

Table and guide for selecting correct welding current based on material thickness.

HOW TO OBTAIN THE BEST WELDING RESULTS

Torch Angle and Movement

Tips on torch angle, movement, and environmental factors for quality welds.

REGULATING THE WELDING MACHINE

Adjusting Wire Speed

How to adjust wire speed for optimal welding results based on sound.

TROUBLESHOOTING

Common Welding Problems and Solutions

Table listing common defects and their causes and solutions.

WIRE LINER REPLACEMENT

Replacing the Wire Liner

Step-by-step guide for replacing the wire liner in the torch.

INSTALLATION INSTRUCTIONS FOR INDOOR WATER COOLING SYTEM

Cooling System Component Connections

Detailed steps for connecting the cooling system components.

SPARE PARTS

Identification of Key Spare Parts

Visual identification of major spare parts within the machine.

BLOCK DIAGRAM TM230-TM260

Electrical Component Overview

Schematic representation of electrical components for TM230/TM260.

BLOCK DIAGRAM TM300

Electrical Component Overview

Schematic representation of electrical components for TM300.

BLOCK DIAGRAM TM350 - TM320 W - TM360 W

Electrical Component Overview

Schematic representation of electrical components for TM350/320W/360W.

BLOCK DIAGRAM TM420 - TM500 W - TM650 W

Electrical Component Overview

Schematic representation of electrical components for TM420/500W/650W.
