Basic Specification
Remote controller
Net weight：About 373g
Dimensions：203.8×91×46.6mm
Operating frequency：2.400-2.4835GHz
Type：Rechargeable lithium battery
Capacity：3900mAh
Nominal voltage：3.7V
Input：5 V 2A
Max transmission distance：About 10000m*
Operating temperature：0 ~ 40°C
Suitable altitude：≤5000m
Drone
Product model：FMWRJ03A9
Dimensions：204×106×72.6mm
Diagonal size：372mm
Take off weight：Smart battery about 780g/The
intelligent flight battery plus about 830g（unInstall the megaphone module)
Flight time：Smart battery about 40min*/The
intelligent flight battery plus about 47min*（unInstall the megaphone module)
Max ascending speed：5m/s
Max descending speed：4m/s
Max flight speed：18m/s
Satellite positioning systems：GPS/BEIDOU/Galileo/GLONASS
Operating temperature：0°C ~ 40°C
Suitable altitude(Intelligent Flight Battery)：≤5000m
Suitable altitude(Intelligent Flight Battery Plus)：≤4000m
Operating frequency：2.400-2.4835GHz
Data interface：12-PIN data interface(femal)
Charger
Rated input：100-240V 50/60Hz 1.45A
Rated output：17.6V 3.5A
Rated power：61.6W
Gimbal
Controllable rotation range：0°~ -90°（Pitch）
Angular vibration range：± 0.005°
Lens：FOV 85°
Camera aperture：f1.7
Camera focal distance：6.81mm
Equivalent focal distance：24mm
Sensor：1/1.3” CMOS
Effective pixels: Max 4800W
ISO range：100 - 6400
Shutter speed：32 ~ 1/8000s
Max video resolution：3840 x 2160 | 30fps | 25fps | 24fps
Max birate: 100Mbps
File system：FAT32/exFAT
Image format：JPG/DNG
Video format：MP4(H.265)
Memory card type：Micro SD8 ~ 256GB
( Class 10 or U3 and above )
Note：
The 40/47 mins flight time refers to the situation where the battery is relatively new and fully charged, and the video recording is turned off during a constant speed flight at 6-8m/s (in a windless environment) without the
Megaphone with release-and-drop module. Remote control distance reach to 15km (FCC) in open area and no interference . All above testing and data come from FIMI laboratory, errors may occur in actual use for
operating and environmental changes.
