Glass Installation Process
• Note: Check all glass edges and surfaces for damage. Do not install the glass if it is damaged. Check that
the insulating material (ladder rope around the outer edge of the glass and around the opening of the fire) is
complete and undamaged. Do not install the glass if the insulating material is damaged or missing.
• Carefully install the glass, which is held in place by retaining clips at the top sides of the glass and powerful
magnets in each lower corner.
• On the back corners of the glass there are 3mm steel magnet panels. In one
Movement, gently lower the glass down allowing the steel magnet panels to
catch the top front face of he magnetic. Take care lowering the glass
completely down into position. The glass will lower onto a 3mm safety
switch pin. There is a safety switch at the left base of the glass panel.
• Gently push the top corners of the glass back into position.
• Tighten the 4mm cap screws that hold the glass retaining clips in
position. Make sure the retaining clips sit flat onto the glass surface.
