3.1 DIP Switch Settings
The following tables list the programmable features for the MS-2 and MS-4. Placing a
DIP switch in the ON position will select the feature while placing the DIP switch in the
OFF position will deselect the feature. The exceptions to this rule are SW3 DIP
switches 5 & 6. These two switches are used to select the Notification Appliance
Circuit synchronization feature. A detailed description of each feature is presented in
the following pages.
Important: When any programmable feature is changed by repositioning a DIP switch,
the FACP Reset button must be pressed to ensure that the control panel can read the
new switch position.
Table 3.1 MS-2 DIP Switch Settings
Switch Number DIP Switch Number DIP Switch ON
SW1
1 Silence Inhibit
2 Auto-silence
3 Temporal Coding
4 Selective Silence (if sync. enabled)
5 Trouble Reminder
6 AC Trouble Delay
7 Autoresettable Supervisory
8 IDC Combination Waterflow/
Supervisory Circuit
SW2
1 not used
2 not used
3 IDC1 Verification
4 IDC1 Supervisory
5 IDC2 Verification
6 IDC2 Supervisory
7 not used
8 not used
SW3
1 NAC1 Nonsilenceable
2 NAC1 Disable
3 not used
4 not used
5 & 6
used to select strobe
synchronization feature as
shown to the right
Switch 5 Switch 6
No Synchronization OFF OFF
System Sensor Synchronization ON OFF
Gentex Synchronization OFF ON
Wheelock Synchronization ON ON
7 Nonsilenceable Waterflow for
Combination Circuit
(only if SW1 switch 8 is ON)
8spare
