DIP Switch Settings Program Options via DIP Switch
MS-2/MS-4 PN 51512:D 10/18/04 33
Table 3.2 MS-4 DIP Switch Settings
Switch Number DIP Switch Number DIP Switch ON
SW1
1 Silence Inhibit
2 Auto-silence
3 Temporal Coding
4 Selective Silence (if sync. enabled)
5 Trouble Reminder
6 AC Trouble Delay
7 Autoresettable Supervisory
8 IDC Combination Waterflow/
Supervisory Circuit
SW2
1 IDC1 Verification
2 IDC1 Supervisory
3 IDC2 Verification
4 IDC2 Supervisory
5 IDC3 Verification
6 IDC3 Supervisory
7 IDC4 Verification
8 IDC4 Supervisory
SW3
1 NAC1 Nonsilenceable
2 NAC1 Disable
3 NAC2 Nonsilenceable
4 NAC2 Disable
5 & 6
used to select strobe
synchronization feature as
shown to the right
Switch 5 Switch 6
No Synchronization OFF OFF
System Sensor Synchronization ON OFF
Gentex Synchronization OFF ON
Wheelock Synchronization ON ON
7 Nonsilenceable Waterflow for
Combination Circuit
(only if SW1 switch 8 is ON)
8spare
