Page 14 of 28
®
DUAL
Integrated Fire Protection System
OWNER'S OPERATION & MAINTENANCE MANUAL
FM-0860-0-31F
Figure 4.6 - FIREFLEX
®
DUAL - NOVEC 1230 trim
Components:
A Cylinder
B Cylinder valve
C Electric actuator
D Pressure gauge c/w Low cylinder pressure switch
E Liquid level indicator
F Bracket
G Discharge pressure switch (optional)
H Mechanical actuator (optional)
FM-076Z-0-16B-2
FIREFLEX DUAL base
(shown without enclosure)
F
A
F
E
G
C
D
B
H
Field connection
to NOVEC 1230 piping
