FireFlex DUAL - Page 30

Page 26 of 28
®
DUAL
Integrated Fire Protection System
OWNER'S OPERATION & MAINTENANCE MANUAL
FM-0860-0-31F
Figure 2 - Cabinet dimensions
Table 8.1 - Cabinet dimensions
Size A B C D E F G
36"
35¾" 25" 77⅛" 39¾" 15" 37¾" 12¾"
46"
46" 25" 77⅛" 50" 15" 48" 23"
54"
54" 31" 81" 58" 21" 56" 26"
Table 8.2 - Preaction piping installation
H
J
K
L
M
N1
N2
O
P
Q
2"
11½" 8" 5"
9¾"
45"
48⅞"
4" 11½" 3½"
3"
11½" 9" 4" 9½" 45"
48
⅞"
4"
12¾"
3"
Notes:
1. N1 refers to 36" or 46" cabinet. N2 refers to 54" cabinet.
2. Dimensions may slightly differ from real unit.
Table 8.3 - NOVEC 1230 piping installation
Lbs R S T U
40
1"
2
¾"
6" 3¼"
76
1¼"
2
¾"
6" 3¼"
164
1½"
2
¾"
6" 1¾"
322
2"
6
¾"
6" 4¾"
601
2½" 6½" 6" 3¾"
850
3" 9" 7" 5"
B
A
C
D
M
S
Q
R Ø
L
FM-061H-1-49B-1
J
K
O
P
H Ø
2"Ø
U
N
T
J
FM-061H-1-49B-7
12''
MIN
22''
MIN
12''
MIN
E
G
Ø3/4"
F
5''
FM-061H-1-49B-6
