SPECIFICATIONS
Model 'A' Oil Pump Model 'J' Oil Pump
1/4 " FNPT Inlet Port 1/4 " FNPT
1/8 FNPT Outlet Port 1/8 " FNPT
40-60 PSI Pressure Range 20-40 PSI
6 GPH Max. Flow 18 GPH
3450 RPM Max Allowable Speed 3450
RPM
1/4 HP 1/4
CW Shaft End Rotation CW Shaft End
20” Hg Max Operating Vacuum 20" Hg
10’ Vertical Maximum Suggested Lift 10' Vertical
<30’, use 3/4” pipe Horizontal Suction Piping <30', use 3/4" pipe
30-90’, use 1” pipe Horizontal Suction Piping 30-90', use 1" pipe
Maximum Fuel Consumption
Model U.S. Gal./Hr. liters/hr Model U.S. Gal./Hr. liters/hr
155 1.1 4.2 200 1.43 5.41
Model U.S. Gal./Hr. liters/hr 245 1.75 6.62 315 2.25 8.52
235 1.6 6 350 2.5 9.46 500 3.6 13.6
Air Pump (Burner mounted, fits all but Mdl 350, 500) 3450 rpm, filtered inlet, 20 psi discharge.
Minimum Heater Clearances
Above: 6"(15cm) Inlet Blower: 18"(46cm) Rear: 18"(46cm) Chimney Connector: 18"(46cm)
Below: 18"(46cm) Outlet Louver: 84"(2.1m) Front: 24”(61cm)
Cabinet Dimensions (includes stack collars but not blower or burner)
Model Length Width Height Weight Hot Air Outlet
155 66”(1.67m) 22”(56cm) 18”(46cm) 150#(68kg) 15” sq. (38cm)
200 79”(2m) 22”(56cm) 22”(56cm) 167#(76kg) 15” sq. (38cm)
245 82”(2.1m) 26”(66cm) 22”(56cm) 200#(91kg) 18” sq. (46cm)
315 96”(2.5m) 26”(66cm) 22”(56cm) 256#(116kg) 18” sq. (46cm)
235 42”(1.1m) 32”(0.8m) 33”(84cm) 350#(160kg) 23x29”(58x74cm)
350 55”(1.4m) 52”(1.32m) 33”(84cm) 800#(364kg) 23x29”(58x74cm)
500 55”(1.4m) 52”(1.32m) 33”(84cm) 800#(364kg) 23x41”(58x104cm)
Overall Dimensions of Heater with Burner and Blower
Model Length Width Height Weight
155 79.5”(2.0m) 22”(56m) 34.5”(88cm) 234#(106kg)
200 92.5”(2.3m) 22”(56m) 34.5”(88cm) 251#(114kg)
245 95.5”(2.3m) 26”(66m) 41”(1m) 348#(158kg)
315 109.5”(2.8m) 26”(66m) 41”(1m) 348#(158kg)
235 52”(1.3m) 42”(1.1m) 33”(0.84m) 480#(217kg)
350 59”(1.5m) 62”(1.57m) 33”(0.84m) 927#(421kg)
500 59”(1.5m) 62”(1.57m) 33”(0.84m) 927#(421kg)
Construction and Specifications: Certified by UL and filed in MH16601 (US & Canada)
Heat Exchanger : Stainless and/or aluminized steel. Exhaust collars 8” (20cm), 10” (25.4cm) model 500.
Stack allows connection to either side (except 350,500). Cap provided must be installed on unused collar.
Cabinet : Mill coated appliance grade painted steel. The louvered opening may be rotated and/or placed
on either side and filler panel is provided and installed on the side opposite the outlet (Except model 350,
500). Burner is attached to a hinged door that allows for easy clean out as well as inspection of nozzle area.
Blower HP (Min.) : Μodel 15, 20, 35: 3/4 HP. Model 24, 31, 50: 1HP
