Page 40 of 40
For a more thorough service the following burner components can be cleaned as a
preventative yearly maintenance.
BLOCK 57181 O-RING 57184 ORING 57182 PLATE 57177
ADAPTER 57179 SCREW (4) 57181
ASSEMBLY OF OIL AND AIR SOLENOID #57190
BASE * O-RING 57194 (ZINC PLUNGER W/ SPRING ASM) 57192
(NICKEL PLUNGER W/ SPRING ASM) 57139
STEM W/ WRENCH FLATS
SNAP RING
COIL
* Pay attention to detail, the solenoid base has a specific inlet and outlet direction.
