Cabinet, Heat Exchanger for WO-F235 3-pass (Previously Model WO-F200)
Key Item # Item Description
Cabinet and Fan
A 56451 CAB: TOP F/235 Cabinet, Top
B 56452 CAB: BRNR End F/235 Cabinet, Burner End
C 56443 CAB: Clean-out Door 175/235 Cabinet, Clean out Door
56454 CAB: Door w handle F/175/235 Cabinet, Door with Handle (exhaust side)
D 56455 CAB: Fan Side 235 Cabinet, Fan Side
56456 CAB: LVR Side Upper PNL 235 Cabinet, Louver Side – Upper Panel
56457 CAB: LVR Side –Side PNL Cabinet, Louver Side - Side Panel
56458 CAB: LVR Side LWR PNL 235 PNTD Cabinet, Louver Side – Lower Side
E 56846
LVR: w/ bolts 235/350
Louver with Bolts, Each (5 louvers required)
F 56419 Switch: Fan 5” UOF 5” Fan Switch ( for top mounted switches)
56420 Switch: 8” 8” Fan Switch (only for switches mounted next
to burner)
G 56427 Motor: Fan ½ HP ½ HP Fan Motor Only, 1075 RPM
56994 Fan Motor ASM: ½ HP 1/2HP Fan Motor Assembly (includes fan
motor, capacitor, electrical box and wiring)
57451
Strap: Fan MTR Capacitor MT
Fan Motor Capacitor Mount Kit
H 56426 Capacitor: Motor, 1 Ouf 6x656 Capacitor for ½ HP Fan Motor
56430 Blade: Fan 175/235 14D ½ Bore Fan Blade
I 56432
Guard: Fan
Fan Guard
56433 Clamp: Fan Guard w/Screws (6) Clamps for Fan Guard with Screws (set fo 6)
J 56955 Junction Box: WL60 & UOF Junction Box
56958 CVR: JCN Box Fan S/W UOF Cover for Junction Box
57266 Strip: Terminal 8 Pole 30 AMP 8 Pole Terminal Strip
Heat Exchanger
56678 Heat EX CAB: 235 L/BRNR & ACC Heat Exchanger Aluminized with Cabinet, less
Burner and Accessories
56669 Heat EX L/CAB: 235 L/BRNR, ACC Heat Exchanger Aluminized, less Cabinet, less
Burner and Accessories
56950 CLNOUT DR: HT EX 175/235 Clean-Out Door for heat Exchanger
K 57267 Sight Plate: New Style 175++ Sight Plate
57270 Spring: Compression Music Wire Compression Spring for Sight Glass Door
56819 Sight Plate Retrofit Kit Conversion Kit for sight Plate Assembly
L 57269
Glass: Sight
Sight Glass
57279 DR: w/Outlet Collar 175/235 Door with Outlet Collar for Bolt in Baffle
57272 Baffle: Bolt In Stainless Steel Bolt in Baffle
57276 Smoke Outlet W/SS Baffle Door with Smoke Outlet Plate and Stainless
Steel Baffle
56824 Target Shield: SS +Nut 175/235 Stainless Steel Target Shield with Lock Nuts
56965 Baffle: SS Repl W/GSKT RETNRS Stainless Steel Replacement Baffle
56608 Target: 175/235 Ceramic w/Bolts Target Shield
54756 Reinforcement Plate: Per pair Reinforcement Plate
56917 Rope: Fiberglass Braid 5/8” 5/8” Fiberglass Rope Gasket – per foot (14’ per
unit required
To Next Page
