CONTENTS
REV 1 - 1603020805
L-C2-436
To protect against electric shock, do not immerse cord or plugs in water or other liquid.
Unplug from the outlet when not in use and before cleaning. Allow to cool before putting on or taking off
parts.
Do not operate any outdoor cooking gas appliance with a damaged cord, plug, or after the appliance
malfunctions or has been damaged in any manner. Contact the manufacturer for repair.
Do not let the cord hang over the edge of a table or touch hot surfaces.
Do not use an outdoor cooking gas appliance for purposes other than intended.
When connecting, fi rst connect plug to the outdoor cooking gas appliance then plug appliance into the outlet.
Use only a properly wired and inspected 120VAC (15 AMP minimum) Ground Fault Circuit Interrupter (GFCI)
GROUNDED 3-wire receptacle with this outdoor cooking gas appliance.
Never remove the grounding plug or use with an adapter of 2 prongs.
Use only extension cords with a 3 prong grounding plug, rated for the power of the equipment, and
approved for outdoor use with a W-A marking.
GETTING STARTED
ELECTRICAL SAFETY .................................................3
REPLACEMENT PARTS LIST .......................................4
MODEL SPECIFICATIONS ............................................ 6
MODEL SPECIFICATIONS TABLE ..............................6
POST PATIO MOUNT GRILL DIMENSIONS TABLE ........6
IN-GROUND POST GRILL DIMENSIONS TABLE ...........7
POST GRILL WIRING DIAGRAM .................................8
GRILL MAINTENANCE AND
SAFETY INFORMATION ..............................................9
ELECTRICAL CONNECTIONS ....................................9
LIGHT SWITCH ........................................................ 9
INSTALLATION REQUIREMENTS .............................10
OVERHEAD CONSTRUCTION REQUIREMENTS
(IF APPLICABLE)
...................................................10
SIDE AND REAR WALL CLEARANCES .......................10
ENSURE PROPER COMBUSTION AIR AND
COOLING AIRFLOW
............................................... 11
EXHAUST REMOVAL ..............................................11
GAS SUPPLY PLUMBING REQUIREMENTS ...............11
PROPANE SAFETY INFORMATION ...........................12
WARNING ............................................................. 12
INSTALLATION SAFETY GUIDELINES.......................12
OPERATING THE UNIT SAFELY AND CORRECTLY .12
SAFE USE & MAINTENANCE OF
PROPANE GAS CYLINDERS ......................................13
INSTALLATION
PATIO MOUNT INSTALLATION .................................15
IN-GROUND POST INSTALLATION ...........................17
FLAVOR GRID & RIGID SHELF INSTALLATION ....... 20
USE, CARE, & SERVICE
IDENTIFICATION OF GRILL CONTROLS ..................21
LIGHTING (IGNITION) INSTRUCTIONS ....................23
ELECTRONIC LIGHTING ........................................23
MANUAL LIGHTING ...............................................23
SETTING THE TIMER .............................................23
SHUTTING OFF THE UNIT ...................................... 23
OPTIONAL DIGITAL THERMOMETER ......................24
OPTIONAL ROTISSERIE ............................................27
OPTIONAL INFRARED BURNER OPERATION ..........28
ACCESSORIES ............................................................ 29
FIRE MAGIC
®
DRIP TRAY .........................................30
CARE & CLEANING ...................................................31
REPLACING HALOGEN BULBS ................................32
CONVERT GAS TYPE / CHECK BURNER ORIFICES . 33
BURNER AIR SHUTTER ADJUSTMENT ....................35
CONTROL PANEL REMOVAL ....................................37
NOTES PAGE ..............................................................38
TROUBLESHOOTING ................................................. 39
WARRANTY ...............................................................40
ELECTRICAL SAFETY
