FireMagic Aurora User Manual

5
REPLACEMENT PARTS LIST (cont.)
REV 1 - 1603020805
L-C2-436
A430s
Item Description Part No. Qty.
1.
Stainless cooking grid (set of 2) 23542-S-2 1
2.
Flavor grid (set of 2) 3063-S-2 1
3.
Main burner 3042-50 2
4.
Heatshield kit 24177-05 2
5.
Silicone gasket 24177-06 2
6.
Infrared burner *‡ 3060 1
7.
Oven lid 23729-53 1
or Oven lid w/ oven thermometer 23729-55 1
8.
Warming rack* 3672S-M 1
9.
Back burner* 24130-11H 1
10.
Back burner cover* 24148-010 1
11.
Patio base w/ hardware *
†
24330-31 1
or
In-ground base w/ hardware *
†
24330-32 1
12.
Rotisserie motor* 3600-02 1
13.
Rotisserie rod* 3603-30 1
14.
Rotisserie knob* 24187-16 1
15.
Meat holder (pair)* 3613 1
16.
Counterbalance* 3620E 1
17.
Grid lifter 3519 1
18.
Convertible regulator PR-4 1
19.
Valve manifold w/ back burner 24130-22 1
or
Valve manifold w/o back burner 24130-28 1
20.
Control panel w/ back burner, w/
digital thermometer
24130-45 1
or
Control panel w/ back burner, w/o
digital thermometer
24130-47 1
or
Control panel w/o back burner, w/
digital thermometer
24130-46 1
or
Control panel w/o back burner, w/o
digital thermometer
24130-48 1
21.
Small knob * 3016 1
22.
Large knob 3015 2
A430s
Item Description Part No. Qty.
23.
Digital thermometer 24180-12H 1
or
Oven hood thermometer ‡ 23305 1
24.
Meat probe * 24187-14S 1
25.
Drip tray 3084 1
26.
Drip tray liner (set of 4) 3557 1
27.
Rigid shelf (left) 24330-017L 1
28.
Rigid shelf (right) 24330-017R 1
29.
Patio mount hardware kit
(if applicable)
24330-25 1
30.
Timer valve (1 hour) 3092A 1
31.
Propane regulator / hose assy. *‡ 5110-07 1
or
Natural Gas QD hose *‡ 5110-03 1
32.
Wire harness assembly‡ 24177-28 1
33.
Back burner electrode*‡ 4199-52 1
34.
Main burner electrode‡ 3199-72 2
35.
Natural gas orifi ce(s)‡ 3001-42-2 1
36.
Natural back burner gas orifi ce(s)‡ 3001-52-1 1
37.
Propane gas orifi ce(s)‡ 3001-54-2 1
38.
Propane back burner gas
orifi ce(s)‡
3001-59-1 1
39.
Fire Magic
®
cookbook‡ 3595 1
40.
Thermometer wire harness *‡ 24177-25 1
41.
Wire harness extension 24182-53 1
42.
Power supply box w/ connector 24177-12 1
43.
12V / 10 watt halogen light bulb ‡ 24187-15 2
44.
Light lens ‡ 24187-26 2
45.
Lamp assembly ‡ 24187-28 2
46.
Light switch 24182-46 1
47.
In-ground post extension only *
†
24330-33 1
48.
Backburner fl ex connector *‡ 3030-01 1
49.
Flash tube (left) ‡ 24187-29 1
50.
Flash tube (right) ‡
24187-35
1
* If equipped
†
For replacement only (not conversion)
‡ Not shown

FireMagic Aurora Specifications

General

Grill Type	Built-In
Ignition System	Electronic
Material	Stainless Steel
Cooking Grid Material	Stainless Steel
Fuel Type	Natural Gas or Propane
Warranty	Lifetime on Stainless Steel Components
