MOUNTING CONTROLLER
NOTE—Consult the appropriate job plans to determine the controller mounting location. Tools and
materials (all mounting) required:
1. Assortment of common hand tools of the type used to service electromechanical equipment.
2. Drill for drilling wall/fl oor anchor holes.
3. Hole (conduit) punch.
4. Hand level.
5. Tape measure.
6. Four anchors with bolts and washers, per enclosure - if wall mount.
7. Mounting hardware for fl oor / wall mount.
Wall Mount— (Optional - If Ordered)
Procedure—
1. Locate bottom mounting brackets and hardware.
2. Inspect for damage.
3. Gently lay the controller on its back, using protection so the paint is not damaged. It is best to lay
the controller in a location that is out of the way from actual mounting location.
4. Remove existing fl oor mounting legs if supplied. Attach each bracket to the bottom of the en-
closure using the supplied hardware . Tighten nuts securely.
Note—Refer to the controller dimension drawing for necessary mounting dimensions.
The controller is wall mounted by using at least four (4) wall anchors, 2 or more anchors for the
top ears and 2 or more anchors for the bottom mounting brackets (depending on enclosure size).
The ears and brackets are dimensionally on the same center-line for ease in mounting.
5. Using either the dimension print or by measuring the distance between the center lines of the
lower bracket slots, transcribe this dimension onto the wall. Note: The bottom edge of the en-
closure should be a minimum of 12” (305 mm.) from the fl oor in case fl ooding of the pump room
occurs.
6. Drill and put anchors into the wall for the lower bracket slot mounts.
7. Mark on the wall, the location of the holes in the upper mounting ears.
8. Drill and put anchors into wall for the upper mounts.
9. Install bolts and washers in lower anchors, leaving a gap between the washer and wall.
10. Lift the controller and place the bottom mounting slots down onto the lower anchor bolts. Do
not tighten bolts.
11. Align holes in upper mounting ears and install bolts and washers in anchors.
12. Shim anchors as necessary to ensure rear of enclosure is vertically level and enclosure is not
stressed. Tighten all anchor bolts.
13. Check to be sure enclosure door opens and closes freely and that enclosure is level.
FLOOR/BASE PLATE MOUNT
MOUNTING LEGS
PROCEDURE- (If not pre installed)
1. If legs were supplied, unpack the legs and mounting hardware.
2. Inspect legs for damage.
3. Securely lift controller or lay it on it’s back being careful not to damage painted surface.
WARNING
RISK OF PERSONAL INJURY
Controller cannot stand upright with the bottom
mounting brackets attached. Leave laying on its
back until the wall anchors are ready for controller
installation.
