10
2. Type in Y to change the message. The screen will display: * (The asterisk indicates a ready
prompt)
3. Type in the customized message (up to 40 characters in length) and press RETURN.
4. To verify the programmed message, type in the command again (e.g..T23) and press RETURN.
The screen will display:
.T23
HIGH STACK TEMP (or customized message)
CHANGE MESSAGE Y/N
5. Type in N
REVIEW CUSTOMIZED MESSAGES
The E300 software will store the last 32,000 bytes of data in RAM memory on the computer. The
user can scroll backward or forward through previously entered commands and customized mes-
sages by using the Page Up/Page Down/Up Arrow/Down Arrow keys.
Note: Quitting the E300 software program deletes the commands and messages from RAM memory.
THE ONLY WAY TO DISPLAY THE CUSTOMIZED MESSAGES ON THE ED510 DIS-
PLAY IS TO OPEN THE SAFETY LIMIT WIRED BETWEEN THE APPROPRIATE TER-
MINALS.
The Sub-Menu “E300 MSG SELECT” on the ED510 Display Module will not display the custom-
ized messages, but only display the available lockout messages from its library of messages. (Refer
to Bulletin ED-5101).
IMPORTANT: The E500 Communication Interface will only display the E300 default
messages. The E500 will not display the messages from the available library of messages
or any customized messages.
