5 120V, 30A RV (NEMA TT-30R) – Maximum full load 11 Circuit Breakers – The receptacles are protected by
30 Amp current may be drawn from this 120 Volt receptacle. an AC circuit protector. If the generator is overloaded
6 Battery Power Restore Switch- Restore the battery or an external short circuit occurs, the circuit protector
power to the control module. You must press this will trip. If this occurs, disconnect all electrical loads and
switch and hold for 3 seconds before start the try to determine the cause of the problem before generator,
including recoil start, electric start attempting to use the generator again. If overloading and remote start.
causes the circuit protector to trip, reduce the load.
7 Output Ready Indicator Light – Remains “ON”
Note: Continuous tripping of the circuit protector
during normal operating conditions. Shuts “OFF” may cause damage to generator or equipment. The
when generator is overloaded. circuit protector may be reset by pushing the button
The green AC Power Indicator Light comes on
of the protector.
when the engine starts and generates power.
Page 08
12 DC Circuit Breaker - The circuit protector may be
reset by pushing the button of the protector.
13 Parallel Operation Outlets - These outlets are used
for connecting two FIRMAN inverter generators for
parallel operation. A FIRMAN parallel kit(optional
equipment) is required for parallel operation.
14 12V DC outlet – 8.3 Amp of DC current may be drawn
from this receptacle.
Use this outlet to charge 12V automotive type
batteries ONLY. See 12V DC outlet (Battery Charger)
section.
15 Remote Start Program Button - Use this button
along with the remote control to program the
generator to be started remotely.
16 Remote Start Indicator light - The light will light or
flash depending on the status of the remote start
system.
17 Ground Terminal – Consult an electrician for local
grounding regulations.
18 Outlet Cover - Protect the receptacles from dust and
debris.
19 Fuel Valve Knob
20 Choke Button
21 Recoil Stater
22 12V DC Battery Charger Port - Plug the 120 Volt AC
charger into this port to charge the generator
battery.
23 Remote Holder - to hold remote control for easy
access.
Remote Control Programming
Before the generator can be started , an initial
start-up procedure must be performed so the
generator and the remote control recognize each
other.
NOTE:
YOUR REMOTE CONTROL IS ALREADY
PROGRAMMED IN
FACTORY FOR YOUR CONVENIENCE. AND IT IS
READY TO START THE GENERATOR.
If the remote control is replaced then you will need
to go through following procedure with new
remote control.
1. Flip the engine switch to the "RUN"(l) position.
2. Push the battery
power restore
switch for about 3
seconds and then
release.
