Firman W03383 - Page 43

English Customer Service: 1-844-FIRMAN1Page
33
2. Release the battery retaining rubber belt.
3. Remove the protective cover(rubber sheath) from
battery.
4. Disconnect the black(-) cable from black(-)
terminal on the battery.
Disconnect the red(+) cable from red(+) terminal on
the battery.
5. Pull out the battery and replace with new battery:
12V sealed lead acid 5.5AH
LXWXH:90X70X100mm(3.54X2.76X3.84in)
6. Connect the red(+)battery cable to the positive
terminal of battery first and then connect the
black(-) battery cable to the negative terminal of
battery.
7. Reattach the air cleaner cover.
To avoid electric shock:
ALWAYS connect the positive (+) battery cable (red
boot) first when connecting battery cables.
Rubber Sheath
Battery
Positive(+)
Terminal
Negative(-)
Terminal
Red Cable
Black Cable
WARNING
