W03383 Parts List
NO.
Part Number
Description
Qty.
NO.
Part Number
Description
Qty.
1
330713500
Fuel Tank Cap
1
67
330713566
Fixed Handle,Left
1
2
330713501
Spillway,Fuel Tank
1
68
330713567
Supporter,Handle Left(Engine)
1
3
330713502
Screw M5×20
6
69
330713568
Supporter,Handle Right(Engine)
1
4
330713503
Cover,top
1
70
330713569
Cover,Left Side
1
5
330713504
Fuel Filter Assembly
1
71
330713570
Screw ST4.8×13
1
6
330713505
Screw M6×12
4
72
330713571
Cover Plate,Left
1
7
330713506
Fuel Tank
1
73
330713572
Air Cleaner Cover
1
8
330713507
Inline Fuel Filter Assembly
1
74
330713642
Control Unit Module
1
9
330713508
Clamp(Ø10.5×8)
1
75
330713574
Rectifier
1
10
330713509
Clamp(Ø 8.7×8)
3
76
330713575
Flange Bolt M6×25
1
11
330713510
Fuel Hose 1
1
77
330713626
Stents,Fuel Valve
1
12
330713511
Fuel Hose 2
1
78
330713577
Fuel Valve Bracket
1
13
330713512
Clamp(Ø8×6)
1
79
330713634
Front Cover
1
14
330713635
Fuel Hose 3
1
80
330713627
Guide,Rope
1
15
330713514
Gasket,Exhaust
1
81
330713628
Button,Choke Assy.
1
16
330713515
Muffler Protector Assembly,Lower
1
82
330713581
Fuel Valve Knob
1
17
330713516
Muffler Assembly
1
83
330713582
Screw/Washer Assembly M4×14
3
18
330713517
Flange Bolt M6×12
5
84
330713583
Cap,Wheel
2
19
330713518
Screw/Washer Assembly M5×14
2
85
330713584
Retaining Ring Ø12
2
20
330713519
Cover,Spark Arrester
1
86
330713585
Washer Ø12
2
21
330713520
Spark Arrester
1
87
330713586
Wheel
2
22
330713521
Nut M6
1
88
330713587
Axle
2
23
330713522
Muffler Protector Assembly,Upper
1
89
330713588
Base Assy.
1
24
330713523
Screw ST4.2×16
6
90
330713589
Rubber Plug
1
25
330713524
Supporter,Maintenance Cover
1
91
330713590
Lock Nut M6
8
26
330713525
Cage Nut M5
12
92
330713591
Screw/Washer Assembly M5×38
2
27
330713526
Maintenance Cover
1
93
330713592
Control Box
1
28
330713527
Bolt M6×16
8
94
330713593
Receptacle USB
1
29
330713528
Handle,Right
1
95
330713594
20A Breaker,Push Button
1
30
330713529
Bolt M8×16
2
96
330713595
LED Indicator Assy.
1
31
330713530
Washer(Ø13×Ø20×2.5)
2
97
330713596
Nut M4
8
32
330713531
Bushing(Ø13.3×Ø19.3×2)
2
98
330713597
Control Panel
1
99
330713617
Ignition Switch
1
33
330713532
Handle Bracket,Right
1
100
330713599
Switch,Economy(ECO)
1
34
330713533
Bolt M6×12
4
101
330713600
Receptacle TT-30R
1
35
330713534
Bushing(Ø13.3×Ø19.3×8)
2
102
330713601
Receptacle Cover, TT-30R
1
36
330713535
Pivot Bracket
2
103
330713602
Parallel Cover
2
37
330713536
Supporter,Right
1
104
330713603
Parallel Outlets
2
38
330713537
Supporter,Left
1
105
330713604
Receptacle Cover,5-20R Duplex
1
39
330713538
Handle Bracket,Left
1
106
330713605
Screw/Washer Assembly M3×10
3
40
330713539
Handle,Left
1
107
330713606
Receptacle Cover,DC 12V
1
41
330713540
Handle,Upper
1
108
330713607
Receptacle 5-20R Duplex
1
42
330713541
Handle,Lower
1
109
330713608
Receptacle DC 12V
1
43
330713542
Screw M5×14
41
110
330713609
Nut M5
1
44
330713543
Flange Bolt M6×35
2
111
330713610
Nut M5
1
