Universal Security Control Module
Install.myfirstech.com
CM2500
Master
Guide
FT-RFID
The CM2500 will support the FT-RFID function, now included with a few of the latest remotes from
Firstech, will unlock/disarm the vehicle when in range of the antenna. In case where a proximity kit is
being added to an existing system (other than AM/AP) please see 2. install prep for RFID using the
Gray data port below.
1. Install prep for FT-RFID using RF port
STEP 1: Set Option 1-15 to Setting 1 or 2, or option 3 is “OFF”
STEP 2: Connect the antenna using supplied 4 pin to 6 pin antenna cable.
STEP 3: Antenna mounting requirements will vary with the vehicle type. The proximity
unlocking range is approximately 3-6 ft from the antenna based on its mounting location.
Testing The FT-RFID
STEP 1: Make sure your FT remotes are programmed. AM/AP remotes will program to the 1W-
AF proximity antenna.
STEP 2: Enable the proximity unlock feature on your FT remote using the remote menu (when
applicable).
STEP 3: Proximity unlock/disarm - Once the CM has been locked/armed allow 15 seconds for
the RFID remote to unlock/disarm the system once its within proximity
(approximately 3ft-6ft) of the antenna. I.e. Arm the system wait 15 seconds walk up to
the vehicle and it will automatically unlock/disarm.
2. Install prep for FT-RFID using GRAY DATA port (remote programming sequence is the
same)
STEP 1: Set Option 1-15 to Setting 1 or 2, or option 3 is “OFF”
STEP 2: Set feature 3 – 01 to option 3 (changes Gray port to support RFID antenna)
STEP 3: Set feature 3 – 07 to option 2 (changes the Black port to support Drone)
