Universal Security Control Module
Install.myfirstech.com
CM2500
Master
Guide
STEP 4: Connect the antenna using supplied 4 pin to 6 pin antenna cable, along with the short
RF to DATA adapter included with the RF kit, to the GRAY DATA PORT
STEP 5: IF there is a Drone, connect it to the Black DATA PORT. In the case of Drone and
data interface module, the interface module will need to be connected to the CM2500
wire to wire.
STEP 6: Antenna mounting requirements will vary with the vehicle type. The proximity
unlocking range is approximately 3-6 ft from the antenna based on its mounting location.
Testing The FT-RFID
STEP 1: Make sure your FT remotes are programmed (programming procedure will be the
same). AM/AP remotes will program to the 1W-AF proximity antenna.
STEP 2 : Proximity unlock/disarm - Once the CM has been locked/armed allow 15 seconds for
the RFID remote to unlock/disarm the system once its within proximity
(approximately 3ft-6ft) of the antenna. I.e. Arm the system wait 15 seconds walk up to
the vehicle and it will automatically unlock/disarm.
NOTE: For Passive Arming/Locking + RFID information please see feature 1-08 option 4
Hood Pin
The CM2500 kit does include a hood pin which can trigger the alarm in the event the hood is opened
while the system is armed.
