FISCHER [CF] EASY - Page 84

C6.1.6/0513-0515/E 31
Appendix 1: Overview of the unit components
Components
Medium temperature
Medium temperature
Low temperature
Standard
Digital
Standard
CFME
CFDE
CFLE
Compressor M1
Fan M2.1
Fan M2.2
CFME050 – CFME075
CFLE050 & CFLE060
Y1 DGS solenoid valve
[-]
[-]
E1 Crankcase heater
S1 High pressure switch
S2 Low pressure switch
S3 Room thermostat (optional)
[-]
[-]
[-]
B1 Pressure transducer suction
B2 Pressure transducer discharge
B3 DLT NTC discharge
B4 EVI vapour in sensor NTC
[-]
[-]
B5 EVI vapour out sensor NTC
[-]
[-]
B6 Ambient temperature sensor NTC
B7 Temperature sensor (optional)
[-]
[-]
[-]
Y2 Stepper valve EVI
[-]
[-]
Y2 Stepper valve liquid
[-]
[-]
Table 23: Overview of the unit components
