Fisher & Paykel ActiveSmart RS90A Installation Instructions

2
3 COMPONENTS LIST
French door
hanging bracket
(2)
Drawer hanging
bracket
(1)
Side bracket
(10)
Side strap
(10)
Top stud
(6)
Side cover
(10)
Top cover
(4)
Screw handle
(12)
Side screw
(10)
Drawer panel
(1)
Door handle
(3)
M8 nut
(6)
M8 washer
(6)
Door panel fittings kit – Included with standard appliance.
Optional accessories kit - The standard appliance does not include door panels. Standard Fisher & Paykel kits are available (EZKleen stainless steel door panels), when designing custom door
panels, these are only available for non-Ice & Water models.
Non-Ice & Water French panel (1)
Ice & Water French panel (1)
Part number: RD90U
Non-Ice & Water French panel (2)
Part number: RD90
Screw washer 4x14
(34)
OR M5 x 14 Mush Phillips SS
(34)
