4
Dimensions
Wash Motor
Pump Motor
Diverter Valve
Electronically commutated 36 pole direct drive 3 phase brushless DC motor.
Motor Resistance @20C (68F):19.5Ω +/- 10% (39Ω +/- 1.95Ω phase to phase)
Electric supply
Operating Voltage: 230V AC 50Hz
Current: 10amps
Inner bowl weight
Height Lid open 1350-1385mm
Lid closed 1045-1075mm
Length Inlet 1200mm
Outlet 1000mm
Width 600mm
Depth 600mm
P1,E1,G1, M1 Weight Packed 57kg
Unpacked 50.2 kg
G2, M2 Weight Packed 55.3kg
Unpacked 47.7kg
Model Material Grade Weight
P1, E1, G1, M1 Stainless steel 430 12.87Kg +/- 112g
G2, M2 Stainless steel 430 8.37Kg +/- 225g
230V 50htz 93Ω +/- 8% @20°c
Note: Thermal cut-out fitted
Wax solenoid 160v DC 1.7KΩ @ 68°F / 20°C
SPECIFICATIONS
