Instruction Manual
D103042X012
D4 Valve
July 2015
2
Table 1. Specifications
Available Configurations
Spring‐to‐Close
Spring‐to‐Open
Valve Body Sizes and End Connection Styles
(1)
See table 2
Maximum Inlet Pressures and Temperatures
(1)
If the valve nameplate shows an ASME
pressure‐temperature class, maximum inlet pressure
and temperature is consistent with the applicable
class per ASME B16.34. If the nameplate does not
show an ASME class, it will show a maximum cold
working pressure at 38_C (100_F) (for example, 293
bar [4250 psi])
Maximum Pressure Drops
(1)
See tables 4, 5, 6, and 7
Input Signal to Actuator
See tables 4, 5, 6, and 7
Actuator Maximum Casing Pressure
(1)
3.4 bar (50 psig)
Shutoff Classification per ANSI/FCI 70‐2
and IEC 60534‐4
Class IV
Material Temperature Capabilities
(1)
Actuator Assembly: -40 to 93°C (-40 to 200°F)
Valve Body Assembly:
Standard Bonnet O‐Ring: -40 to 135°C (-40 to 275°F)
Optional Fluorocarbon Bonnet O‐Ring: -23 to 204°C
(-10 to 400°F)
Flow Characteristic
Equal percentage
Flow Direction
Flow up only
Port Diameters
See table 2
Valve Plug Travel
19 mm (0.75 inch)
Valve Plug Style
Micro‐Form valve plug
Actuator Diaphragm Effective Area
452 cm
2
(69 inches
2
)
Actuator Pressure Connection Size
1/4 NPT internal
1. The pressure or temperature limits in the referenced tables and any applicable ASME code limitations should not be exceeded.
Specifications
Table 1 lists specifications for the D4 control valve. Some of the specifications for a given control valve as it originally
comes from the factory are stamped on a nameplate located on the actuator spring barrel.
Educational Services
For information on available courses for Fisher D4 valves, as well as a variety of other products, contact:
Emerson Process Management
Educational Services - Registration
Phone: 1-641-754-3771 or 1-800-338-8158
E-mail: education@emerson.com
http://www.emersonprocess.com/education
