Fisher FIELDVUE DLC3010 Quick Start Guide

Quick Start Guide
D103214X012
DLC3010 Digital Level Controller
February 2016
7
Type n
This equipment shall be used with a cable entry ensuring an IP66 minimum and being in compliance with the relevant
European standards.
Operating ambient temperature: -40_C to + 80_C
Refer to table 3 for additional approval information.
Table 3. Hazardous Area Classifications—ATEX
Certificate Certification Obtained Entity Rating Temperature Code
ATEX
Intrinsically Safe
II 1 G D
Gas
Ex ia IIC T5 Ga
Dust
Ex ia IIIC T83°C Da IP66
Ui = 30 VDC
Ii = 226 mA
Pi = 1.4 W
Ci = 5.5 nF
Li = 0.4 mH
T5 (Tamb ≤ 80°C)
Flameproof
II 2 G D
Gas
Ex d IIC T5 Gb
Dust
Ex tb IIIC T83°C Db IP66
- - - T5 (Tamb ≤ 80°C)
Type n
II 3 G D
Gas
Ex nA IIC T5 Gc
Dust
Ex t IIIC T83°C Dc IP66
- - - T5 (Tamb ≤ 80°C)
IECEx
Intrinsically Safe
The apparatus can only be connected to an intrinsically safe certified equipment and this combination must be
compatible as regards the intrinsically safe rules.
Operating ambient temperature: -40_C to + 80_C
Flameproof, Type n
No special conditions for safe use.
Refer to table 4 for approval information.
Table 4. Hazardous Area Classifications—IECEx
Certificate Certification Obtained Entity Rating Temperature Code
IECEx
Intrinsically Safe
Gas
Ex ia IIC T5 Ga
Dust
Ex ia IIIC T83°C Da IP66
Ui = 30 VDC
Ii = 226 mA
Pi = 1.4 W
Ci = 5.5 nF
Li = 0.4 mH
T5 (Tamb ≤ 80°C)
Flameproof
Gas
Ex d IIC T5 Gb
Dust
Ex t IIIC T83°C Db IP66
- - - T5 (Tamb ≤ 80°C)
Type n
Gas
Ex nA IIC T5 Gc
Dust
Ex t IIIC T83°C Dc IP66
- - - T5 (Tamb ≤ 80°C)
