Fishman AURA SPECTRUM DI - Signal Flow

28
Signal Flow
The illustration below shows the audio signal as it ows through Aura
Spectrum. Note: When Global EQ mode is selected, the tone controls
also affect the Image signal as indicated by
*
(see pages 20 & 21).
input phase
compressor
compressor
Image select
blend
*
low
“insert style” effects loop
fx loop
output
volume
tip = send ring = return
XLR ground is lifted
when 1/4” output is
is connected
mid high
trim
clip | batt
