LIQUID-COUPLED HEAT EXCHANGER ECONET
®
Installation & Maintenance Manual
19
FläktGroup DC_9010GB 20180327_R0 Specifications are subject to alteration without notice
B30 APPLICATION
B31 MANUFACTURER FläktGroup
B32 VERSION v5.xx
B33 TYPE EcoNet
C00 LOG IN Logging in
C10 GIVE
PASSWRD
0 Give password
C20 CHANGE
PASSW
2000 Change password. C20 shown if logged in
D00 CONFIG Configuration of EcoNet parameters
D10 BASIC SETTIN EcoNet basic settings
D11 CONF AIRFLOW Airflow measurement settings
D111 PRESS SENSO PRESS LI-
NEAR
Sensor type
D112 PRESS RANGE 5000Pa Pressure range
D113 K-FACTOR 22.23 Supply fan K-factor for airflow calculation
D12 CONF LIQ FLW Liquid flow calculation
D121 PRESS RANGE 400kPa Sensor range
D122 PRESS LOWER 50kPa Lquid pressure lower
D123 FLOW LOWER 0,5l/s Liquid flow lower
D124 PRESS UPPER 250kPa Liquid pressure upper
D125 FLOW UPPER 2l/s Liquid flow upper
D126 MIN FLOW 0l/s Minimum flow
D127 MAX FLOW SP 2,5l/s Maximum flow
D20 OPER SETTING EcoNet operational settings
D21 OPT HEAT REC Optimal heat recovery curve
D211 AIR LOWER 3m3/s Optimal heating air flow lower
D212 LIQ. LOWER 1l/s Optimal heating liquid flow lower
D213 AIR UPPER 6m3/s Optimal heating air flow upper
D214 LIQ. UPPER 2l/s Optimal heating liquid flow upper
D22 OPT COOL REC Optimal cooling with cool recovery curve
D221 AIR LOWER 3m3/s Optimal cooling air flow lower
D222 LIQ. LOWER 1l/s Optimal cooling liquid flow lower
D223 AIR UPPER 6m3/s Optimal cooling air flow upper
D224 LIQ. UPPER 2l/s Optimal cooling liquid flow upper
D23 OPT COOLING Optimal cooling without cool recovery curve
D231 AIR LOWER 3m3/s Optimal cooling air flow lower
D232 LIQ. LOWER 1l/s Optimal cooling liquid flow lower
D233 AIR UPPER 6m3/s Optimal cooling air flow upper
D234 LIQ. UPPER 2l/s Optimal cooling liquid flow upper
D24 LAMINAR FLOW Laminar flow setpoint
D241 NOM SETP 0,6l/s Nominal setpoint
D25 IDLE Idle state setpoints
D251 FLOW SETP. 1l/s Liquid flow idle set point
D252 START TEMP. 16°C Heat recovery liquid temperature idle setpoint
Continued on next page
